10 Amp Mini Red Fuse

This 20 Amp fuse is used in FIRST Tech Challenge batteries and the FIRST Robotics Competition Power Distribution Panel (am-2856).

Specifications:

• Color: Yellow
• Amps: 20
• Max Voltage: 32
• Style: MINI®
• Specification: SAE J2077
• Type: Blade Fuse

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

1/2 inch external retaining ring, used in the RAW Box.

Specifications:

• Material: Steel
• For Shaft Diameter: 1/2"
• Thickness: 0.031"
• Type: External Retaining Ring
• Free Inside Diameter: 0.456"
• Plier Hole Diameter: 0.40"
• Weight: 0.002 pounds

Pneumatic fitting with M5 threads and 1/4" push-in tubing port

This fitting screws into a CKD single or double solenoid valve.

Specifications:

• Pisco fitting, part number POC1/4-M5
• Tubing diameter: 1/4 inch
• Mounting thread: M5
• Fastening method: Internal hex (use allen wrench)
• No pipe tape or additional sealant is needed for fastening these fittings
• Pressure rating: 150 psi

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

This Inline Chain Tensioner for #35 series roller chain is perfect to adjust the desired tension in a long run of chain on mechanisms such as elevators and arms. This is ideal where there is at least a ~3" section of chain that never passes over a sprocket in a given mechanism. Pair this with two #35 Master Links and integrate this to your robot for an easy-to-use chain tension solution!

The design of this product was inspired by Misumi's Chain Turnbuckles. This product has been improved to be compatible with imperial-sized wrenches.

Specifications

• Chain Size: #35

Documents

CAD File(s)

am-3914_35 35 Chain Tensioner.STEP

Layout Print(s)

am-3914_35 #35 Chain Inline Tensioner.PDF

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

These custom designed collar clamps have been designed specifically with FIRST Robotics Competition teams in mind. The one-piece collar clamp is a nice fractional 1/2 in. width to make shaft stackups easy. The clamping force is provided by a 10-32 socket head screw, which is bigger than most used in the competition marketplace.  This provides a high-strength clamping solution that shouldn't strip out when you need it most. You can even replace the 10-32 screw if it becomes lost with the screws historically used in the AM14U family of chassis. These thoughtfully designed collar clamps also have small bosses on each side. This allows these collar clamps to be installed directly adjacent to an FR8ZZ Round or FR8ZZ Hex bearing without rubbing on the outer races for smooth operation.
