1/2 in. Steel Hex Shaft Stock - 3ft Length

This item can only be purchased in multiples of 25

Product Overview

These blind steel rivets are a perfect, strong choice for creating frames when using our 1in. Gussets paired with up to .125" wall aluminum tubing. These steel rivets won't let you down when you need them most!

Specifications

• Diameter: 3/16 in.
• Drill Size For Hole: #11
• Finish: Zinc
• Grip Range: 0.126-0.25 in.
• Head: Buttonhead
• Hole Size: 0.192-0.196 in.
• Length: 0.45 in.
• Mandrel Material: Steel
• Material: Steel
• Rivet Style: Blind
• Weight: 0.0094

This item can only be purchased in multiples of 25

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: #10-32
• Thickness: 0.249"
• Thread: Fine
• Thread Size: 32
• Type: Nylon Insert Lock Nut
• Wrench Size: 3/8"

This item can only be purchased in multiples of 25

#10-32 x 0.5 in. long Socket Head Cap Screw

Specifications

• Finish: Zinc
• Head: Socket Cap
• Length: 0.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.1 lbs

This new custom designed collar clamp has been designed specifically with FIRST Robotics Competition teams in mind. This product is Out of Stock until Mid March

This is the "500EX Hex Hub" the bore is a 1/2" Hex Hole. It is a slightly different version of the 500 Hex Hub. It is manufactured differently, as it is extruded. Also, there is a 1.124" diameter boss on each side of the hub flange, providing a location for 1.125" bore flat sprockets. Are you having a hard time keeping your sprocket concentric with your hub? This hub is the trick.

This is the hub featured in the 2014 and 2015 Kit of Parts Drive Chassis and fits all AndyMark wheels.

Specifications:

• Material: 6063 Aluminum
• Bore: 1/2" Hex
• Bolt Pattern: 0.204" diameter holes, evenly spaced on a 1.875" diameter bolt circle
• Outside diameter: 2.25"
• Weight: .088

We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.

On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.

Specifications

• Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
• Material: 6061-T6 Aluminum
• Thickness: 0.125 in

Documents

Layout Print(s)

am-3860 90 Gusset REV2.PDF

am-4158 1IN Tee Gusset.PDF

am-4159 1IN Quad Gusset.PDF

am-4160 1IN 30deg Gusset.PDF

am-4161 1in 45deg Gusset.PDF

am-4162 1in 60deg Gusset.PDF

am-4163 1in 120deg Gusset.PDF

am-4164 1in 135deg Gusset.PDF

am-4165 1in 150deg Gusset.PDF

am-4166 1IN Sport Double Bearing Mount.PDF

am-4167 1IN 57Sport Side Mount Gusset.PDF

am-4168 1IN Bearing Side Mount Gusset.PDF

CAD File(s)

am-3860 90 Gusset REV2.STEP

am-4158 1IN Tee Gusset.STEP

am-4159 1IN Quad Gusset.STEP

am-4160 1IN 30deg Gusset.STEP

am-4161 1in 45deg Gusset.STEP

am-4162 1in 60deg Gusset.STEP

am-4163 1in 120deg Gusset.STEP

am-4164 1in 135deg Gusset.STEP

am-4165 1in 150deg Gusset.STEP

am-4166 1IN Sport Double Bearing Mount.STEP

am-4167 1IN 57Sport Side Mount Gusset.STEP

am-4168 1IN Bearing Side Mount Gusset.STEP

Compliant wheels are not intended for moving robots, but moving objects. Compliant wheels give way to allow rigid objects to be manipulated easily. A line of multiple wheels on a driven hex axle creates a very effective roller that ignores variations in the objects being driven. This makes for high-performance intakes and internal conveyors.

Different durometer ratings give each wheel unique characteristics. Green wheels (35A durometer) are the softest and most compliant around objects, maroon (45A), blue (50A), and black (60A) wheels are increasingly firm. The increased firmness also allows the latter wheels to carry a higher RPM rating. Check out the downloads tab for a chart showing wheels and their maximum RPM.

Specifications

• Bore: 0.375 in. Hex, 0.50 in. Hex, 5 mm Hex
• Core Material: Polycarbonate
• Diameter: 2.25 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.08 lbs
• Width: 1 in.

Documents

Layout Print(s)

am-3949 2.25IN 500Hex HD Compliant Wheel REV3.PDF

am-3950 2.25IN 375Hex HD Compliant Wheel REV3.PDF

am-4536 2.25in HD 5mm Hex Molded Compliant Wheel.PDF

CAD File(s)

am-3949 2.25IN 500Hex HD Compliant Wheel.STEP

am-3950 2.25IN 375Hex HD Compliant Wheel.STEP

am-4536 2IN OverMolded 5mm Hex Compliant Wheel.STEP

This retainer clip is used to hold objects (such as gears) in place on shafts.

Example: This product can be used to hold a gear onto a PG71 motor shaft.

Specification:

• Material: Steel
• Inner Diameter: 3/8"
• Outer Diameter: 0.64"
• Weight: Less than 0.001 lbs

#25 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #25
• Pitch: 0.250 inch
• Weight: 0.01 lbs

FTC Note: This product is NOT legal for FTC, we recommend our Stealth Wheel.

Product Overview:
This is a 6" diameter wheel with a polycarbonate body and a TPU rubber "HiGrip" tread profile. This wheel features a 77A durometer tread material that is durable with long-life wear characteristics. Use this wheel for great tread life and good drivetrain response.

We feel that these wheels are a more durable option for teams' drivetrains. While they provide good traction, they make for a maintenance-free wheel for the average team. Under normal circumstances we feel that these wheels will last most FIRST Robotics Competition teams the entire season.
No bearings or hubs are included in this wheel.

Specifications:

• Diameter: 6 inches
• Body Material: Polycarbonate, black
• Tread Material: TPU rubber, 77a durometer
• Bore: 0.95 inch, with bearing pockets of 1.124 inch diameter x 0.25 inch deep on both sides
• Weight: 0.5 pound
• Bolt Pattern: six holes (0.17 inch diameter) on a 1.875 inch diameter bolt circle
• Coefficient of friction: 0.95-1.0 static (on tight pile carpet)
• Coefficient of friction on HDPE: 0.31
• Side Load: In excess of 600 lbs at tread surface
• Load capacity: 90 pounds

Usage:

• Use #10-24x3/4 thread forming screws to attach sprockets or hubs to this wheel.

With Axle and Hub:

• If you wish to drive this wheel with an Axle and Hub, you can pick your hub by fitting any of the AndyMark hubs (not included) to this wheel. If this is your choice, then no bearing is needed. Use #10-24x3/4 thread forming screws to fasten a hub to this wheel.

With Sprocket:

• If you wish to drive this wheel with a sprocket, then the sprocket needs to be attached to the side of the wheel, and two ball bearingsneed to be pressed into the wheel (one on each side). The ball bearing must have a 1.125" od. For a 1/2" id, use am-0181 or am-0029. For a 3/8" id, use am-0209. Use #10-24x3/4 thread forming screws to fasten the sprocket to the wheel.

With Bearings:

• To press bearings into this wheel (for a free spinning wheel or for use with a sprocket), two ball bearings need to be pressed into the wheel (one on each side). The ball bearing must have a 1.125" od. For a 1/2" id, use am-0181 or am-0029. For a 3/8" id, use am-0209.
