Compliant wheels are not intended for moving robots, but moving objects. Compliant wheels give way to allow rigid objects to be manipulated easily. A line of multiple wheels on a driven hex shaft creates a very effective roller that ignores variations in the objects being driven. This makes for high-performance intakes and internal conveyors. The wheels are sized for an interference fit and tend to stay in place on a shaft, though a shaft collar may be used to make absolutely sure the wheels stay clear of other mechanisms or maintain consistent spacing.

The hex bore versions of this wheel are undersized, and are intended to be an interference fit on their respective hex shafts. This interference fit allows for effective torque transfer from the hex shaft to the wheel, as well as allowing the wheel to remain in place along the shaft without the need for spacers or collar clamps:

Different durometer ratings give each wheel unique characteristics. Green wheels (35A durometer) are the softest and most compliant around objects, while orange (40A), maroon (45A), and blue (50A) wheels are increasingly firm. The increased firmness also allows the latter wheels to carry a higher RPM rating. Check out the downloads tab for a chart showing wheels and their maximum RPM.

Specifications

• Bore: 1/2 in. Hex, 3/8 in. Hex, Nub Bore
• Diameter: 2 in.
• Durometer: 35A (Green), ⠀40A (Orange), ⠀45A (Maroon), ⠀50A (Blue), 60A (Black)
• Hole Pattern: Qty 2 3.5 mm Holes on a 16 mm Circle for 8 mm bore wheels
• Material: TPU
• Maximum RPM: 6000 - 9000
• Weight: 0.035 lb.
• Width: 0.5 in.

Documents

Layout Print(s)

am-3571 2IN 375 Hex Compliant Wheel REV3.PDF

am-3462 2IN 500Hex Compliant Wheel REV3.PDF

am-3572 2IN 8mm Compliant Wheel REV4.PDF

CAD File(s)

am-3571 2IN 375Hex Compliant Wheel REV2.STEP

am-3572 2IN 8mm Compliant Wheel REV2.STEP

am-3462 2IN Molded 500Hex Compliant Wheel REV2.STEP

Additional File(s)

2 inch Compliant Wheel Expansion.pdf

This is a 1/2 in. hex bore bearing that is shielded. This Ball Bearing is a great way to make things spin fast!

#35 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #35
• Pitch: 0.375 inch
• Weight: 0.01 lbs

11 different offerings of our 35 Series Plate Sprockets. These are perfect for meshing with roller chain and finally getting that-thing-that-you-need-to-spin moving!

These Aluminum sprockets work perfectly with any of our 6 hole hubs and mesh with #35 roller chain.

Specifications

• Bolt Circle: 0.206 in. diameter holes on a 1.875 in. diameter circle
• Chain Series: 35
• Inside Diameter: 1.1245 in.
• Material: 6061 Aluminum
• Thickness: 0.168 in.

The Sushi Roller Intake Wheels are an excellent choice for robot intakes, internal conveyors, feeder mechanisms, or anywhere you need a durable, compact and grippy roller. These rollers are made with a robust polycarbonate hex bore hub, so no external hub is necessary - just slide them onto a hex shaft, constrain them axially and you are good to go. Available in a range of durometers for a wide variety of applications, these cute little rollers are great for getting a grip on things!

Specifications

• Bore: 0.5 in. Hex, 5 mm Hex, 0.375 in. Hex
• Core Material: Polycarbonate
• Diameter: 1 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.022 lbs
• Width: 1 in.

Whether you have shafts that are too short or shafts of different types, this coupling will solve every component connection issue you've had! Need to combine multiple hex shafts, multiple 1/2-inch keyed shafts, or convert between hex and keyed? This coupling solves all at a better price than anyone else can offer!

Shaft Compatability

This coupling has geometry to capture 0.50-inch hex shafts with an inside hex of 0.51 to 0.52 inches as well as 0.5 inch keyed shafts with a 1/8th inch keyway with a keyway width of 0.128 inches to 0.131 inches.

#35 Roller Chain, 10 feet

Specifications:

• Material: Steel
• Specification: ASME/ANSI B29.1
• Style: Riveted - Single Strand
• Type: Roller Chain
• Size: #35
• Pitch: 3/8"
• Weight: 2.5 lbs

11 different offerings of our 35 Series Plate Sprockets. These are perfect for meshing with roller chain and finally getting that-thing-that-you-need-to-spin moving!

These Aluminum sprockets work perfectly with any of our 6 hole hubs and mesh with #35 roller chain.

The Planetary Gearbox (PG) series of gearboxes and gearmotors feature robust planetary gearing inside paired with reliable motors. You asked for it, we delivered. This gearbox now features two hex output shaft options to easily attach to 3/8 in. or 1/2 in. hex bore wheels, sprockets, and other motion products without the need for adapters.

This is the cable used for our US Digital E4T Encoder. It comes with pre-fabricated individual AVL connectors, making there no need to crimp your own ends.

Specifications:

• Weight: 0.02 pound
• Connections: Molex connector on 1 end, 4 AVL connectors on other end
• Length: 36 inches
