38mm Omni Wheel

The Studica Light Weight Shaft Hub is used with the 6mm D shafts. It has a 5mm set screw for tight clamping and seven M3 tapped mounting holes.

Specifcation:

• Material: 6061-T6 Aluminum
• 6mm D Shaft ID
• M3 tapped hole pattern for connecting to structure
• Step File

Use this 10-cell, 12-volt rechargeable pack to bring long-lasting power to TETRIX^® motors and electronics. This 3,000 mAh NiMH pack features a built-in, 20-amp replaceable fuse for safety.

(THIS BATTERY IS FTC LEGAL)

This 20 Amp fuse is used in FIRST Tech Challenge batteries and the FIRST Robotics Competition Power Distribution Panel (am-2856).

Specifications:

• Color: Yellow
• Amps: 20
• Max Voltage: 32
• Style: MINI®
• Specification: SAE J2077
• Type: Blade Fuse

Made of aluminum, the Studica Clamping Shaft Hub is used with flex and drive wheels

Specifcation:

• Material: 6061-T6 Aluminum
• 6mm ID
• Hole pattern for connecting to structure
• Step File

This is the cable designed for the encoder that is pre-attached to the NeveRest Series of motors and gearmotors. It has a connector on the opposite end to directly interface with the REV Expansion Hub or the REV Control Hub.

2019 Update:

The 'a' version of this cable as the encoder channels swapped so that the encoder counts in the same direction as the output shaft spins. This simplifies the usage of the encoder with the various programming languages for FTC!

Specifications

• Length: 20 in.

The Studica 30T Servo 25T Spline Gear is used with the Studica Multi-Mode Smart Servo or Studica Multi-Mode Smart Servo 200.

Specifications:

• Material: Steel Hardened, Zinc plated
• Step File

The 6mm Servo Hub 25T is made of anodized 6061-T6 Aluminum and is used to connect a servo motor to a D-Shaft axel.

• Step File

The Studica Flat Beam is 3mm thick and 8mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 8mm
• Length - 192mm
• Step File

This versatile rotary sensor offers a comprehensive solution for measuring both relative and absolute positions, thanks to its ABI quadrature output and absolute position pulse output capabilities. The encoder is thoughtfully designed with a standard 3/8-inch Hex Through Bore, complete with strategically placed mounting holes to seamlessly integrate into various multi-channel systems. Enhancing its adaptability further, the package includes interchangeable inserts, allowing you to effortlessly convert the 3/8-inch hex to a 6mm D-Shaft, 5mm hex, or 7mm hex, providing you with exceptional flexibility for your application needs.

Great for use in an FTC Odometry system along with our 38mm omni wheel.

Specifications:

• Size: 1/10 standard car
• Material: Aluminum alloy
• Total length: 108mm
• Ball head to ball head: 100mm
• Diameter: 17mm
• Ball head hole diameter: 3mm
• Step File - Shock in compressed mode
• Step File - Shock in extended mode
