AfterBurner Output Shaft

This is a Trilobe, thread forming, or thread rolling screw, ideal for applications where the screw is being threaded into plastic or metal.

A flat washer is part of the 5/16 hex head, providing more surface area contact than a regular hex head. The increased bearing area decreases the likeliness of crushing mating surfaces. Trilobe, or Thread Rolling, screws have a blunt tapered point that requires a pre-drilled or punched hole; eliminates chips and permits replacement with standard screw. Zinc plating froms a zinc carbonate film that greatly retards the corrosion rate in a normal atmosphere, which is similar to the aluminum oxide film that forms on aluminum that accounts for its low corrosion rate.

Product Overview:

• Quantity: 50
• Diameter: #10
• Finish: Zinc
• Head: 5/16 Hex with integral washer
• Thread Length: 3/4"
• Material: Steel
• Thread Size: 10-24
• Thread Type: Trilobe, Thread Rolling
• Weight per Screw: 0.007 lbs
• Package Weight: 0.34 lbs

1/2 inch external retaining ring, used in the RAW Box.

Specifications:

• Material: Steel
• For Shaft Diameter: 1/2"
• Thickness: 0.031"
• Type: External Retaining Ring
• Free Inside Diameter: 0.456"
• Plier Hole Diameter: 0.40"
• Weight: 0.002 pounds

This retainer clip is used to hold objects (such as gears) in place on shafts.

Example: This product can be used to hold a gear onto a CIM motor shaft.

Specification:

• Material: Steel
• Inner Diameter: 8mm
• Outer Diameter: 15mm
• Weight: Less than 0.001 lbs

This is a Heavy Duty Hex Bearing which outperforms our previous 1/2" Hex Bearings as it has a Heavy Duty Inner Race. This FR8ZZ-HexHD bearing, 1/2" hex bore, flanged, heavy duty inner race, shielded ball bearing, has an inner race that is thicker and stronger than our recent offering of a similar bearing (am-0279). This bearing has more material between the corners of the hex bore and the edge of the race making it stronger and much less likely to crack under high load.

This bearing is guaranteed to have a stronger, thicker race. 100% of these bearings have been quality checked for a smooth fit over 1/2" hex stock here at AndyMark. Many of our long-time customers will recognize this bearing, as it is the same version we sold back in 2008-2011, and we did not have any failures. Now, it is renamed and quality checked for your high load needs - including drive chassis with cantilevered wheels.

Specifications:

• Inside diameter: 0.500-0.502 inch hex bore
• Outside diameter: 1.125 inch
• Flange thickness: 0.062 inch
• Overall thickness: 0.312 inch
• Weight: 0.05 pound

These adapters are intended to be a high strength solution to adapt the Falcon Spline to any product that has a 1/2 in hex bore. This product includes the correct size washers to retain items along the hex shaft, as well as a thread-patch 8-32 screw to be used in conjunction with spacers included with the Falcon 500 motor to retain motion hardware.

This simple bracket handles so many of your mounting needs! Mount motors or gearboxes anywhere and make axle supports with bearings - it's a do-it-all, put-it-anywhere bearing and motor mount bracket.

Any motor or gearbox with a 2-inch diameter bolt circle can be mounted in this bracket. The center hole is sized to hold a standard 1.125 inch outside diameter bearing.

Examples of motors with a 2 in. diameter bolt circle:

• 2.5 in. CIM Motor
• NEO Brushless Motor

Examples of gearboxes with a 2 in. diameter bolt circle

• PG Series Gearboxes
• 57 Sport Gearbox
• CIM Sport Gearbox
• Falcon Sport Gearbox
• DeCIMate Gearbox

Specifications

• Depth: 1 in.
• Height: 2.679 in.
• Length: 3.5 in.
• Material: 5052 Aluminum
• Thickness: 0.13 in.
• Weight: 0.104 lbs

Documents

Layout Print(s)

am-4244 1IN Pitch Bent Motor and Bearing Bracket REV2.PDF

CAD File(s)

am-4244 1IN Bent Bearing Side Mount Gusset.STEP

The Studica Square Beam is 8mm by 8mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material -  Anodized 6061-T6 Aluminum
• Holes - 3.5mm diameter spaced 8mm apart
• Length - 48mm
• Step File

This bearing plate is a great way to mount 1.125 in. OD (FR8) into thin or weak material that otherwise could not tolerate or support a press-fit.



Specifications:

• Material: 5052 Aluminum
• Bore: Press fit for FR8 bearing
• Thickness: 0.125 in.
• Bolt Pattern: 4x clearance for #10-32 on 2.00" circle
• Length: 1.875 in.
• Width: 1.875 in.
• Weight: 0.0275 in.

Miter gears are a special class of bevel gears where the shafts intersect at 90° and the gear ratio is 1:1. This miter gear has a .500" hex bore, making it perfect for interfacing with many popular products in the competition robotics marketplace.

Specifications:

• Material: 1045 Steel
• Module: 1.25
• Tooth Count: 20
• Pressure Angle: 20
• Pitch Diameter: 0.980 in
• Mounting Distance: 0.910 in
• Hub Depth: 0.350 in
• Hub Diameter: 0.870 in
• Bore: 0.50 in Hex
• Weight: 0.056 Pounds

Miter gears are a special class of bevel gears where the shafts intersect at 90° and the gear ratio is 1:1. This miter gear has a 8mm bore with a 2mm keyway, fitting perfectly on a CIM motor shaft.

Specifications:

• Material: 1045 Steel
• Module: 1.25
• Tooth Count: 20
• Pressure Angle: 20
• Pitch Diameter: 0.980 in
• Mounting Distance: 0.910 in
• Hub Depth: 0.350 in
• Hub Diameter: 0.870 in
• Bore: 8 mm with 2 mm keyway
• Weight: 0.078 Pounds
