CENTERSTAGE℠ Tape Set

These aluminum 5M HTD Pulleys work great for creating belt reductions directly off the motor. Use a 15mm wide belt or two 9mm wide belts as the inside pulley teeth are 18.5mm wide. Choose either 8mm keyed bore or spline bore depending on the motor type you're using.

Build high-response robots with the LEGO^® Technic^™ Medium Angular Motor featuring low-profile design, integrated rotation sensor with absolute positioning and 1-degree accuracy.

• Ideal for lower-load, fast-response applications.
• Low-profile design for smaller models where space is limited.
• Absolute positioning and integrated rotation sensor for true straight-line control.
• Tacho feedback control for 1° accuracy.
• Zero-point markings for simple calibration.
• Simple form factor for quick building and rebuilding.

This is a 25 foot section of a twisted pair of 22 AWG wire.

Specifications

• Gauge: 22 AWG
• Length: 25 feet

CENTERSTAGE℠ Presented by Raytheon Technologies is the 2023-2024 FIRST® Tech Challenge game. Teams will raise the curtain on the power of design, creativity, and precision to create all new experiences. Read more about CENTERSTAGE℠ on the FIRST® website.Game

The 100mm (4") Flex Wheel can be used for intake systems and conveyors.

Specifications:

• Diameter:   100mm (4")
• Axial width:  25mm
• Hub:  1/2" Inner Hex
• Inner Material: Molded Plastic in Yellow
• Outer Material: TPU Polyurethane in Green
• Outer Material Durometer: 35A
• Weight: 0.038kg
• Step File

The Intake Kit can be used to create intake systems and is ideal for the FIRST Technical Challenge (FTC) and World Robotics Olympiad (WRO). Used with the Silicone Rubber Tubing #76410

Specifications:

• Main piece
  • hex width: 20.78mm*10.0mm thick
  • 6*M6 tapped holes
  • 1*M4 tappped hole for M4 set screw
  • 6.0mm Diameter D Hole
  • Material AL6061-T6
  • Φ7.5mm*14.0mm
• Pins
  • 6PCS in a pack
  • M6*4.0mm thread
  • Material SS303
• Step file

Φ29.0mm*16.0mm thick
6*M3 thread tapping through
(including 2*M3 thread for M3 SHCS)
Φ6.0mm D hole
AL6061-T6

Used with the Intake Kit to create various intake system with various lengths.

• ID: 6mm
• OD: 10mm
• 1000mm long
• Wall Thickness: 2mm
• Flexible
• Bend Radius: ~30mm
• Silicone
• Durometer: 70A
• Black
• Step File

The LEGO^® Education SPIKE^™ Prime Set is the go-to STEAM learning tool for grade 6-8 students. Combining colorful LEGO building elements, easy-to-use hardware, and an intuitive drag-and-drop coding language based on Scratch, SPIKE Prime continuously engages students through playful learning activities to think critically and solve complex problems, regardless of their learning level. From easy-entry projects to limitless creative design possibilities, including the option to explore text-based coding with Python, SPIKE Prime helps students learn the essential STEAM and 21st century skills needed to become the innovative minds of tomorrow... while having fun!

LEGO EDUCATION SPIKE PRIME
