CKD Manifold Blank Cover

Pneumatic fitting with M5 threads and 1/4" push-in tubing port

This fitting screws into a CKD single or double solenoid valve.

Specifications:

• Pisco fitting, part number POC1/4-M5
• Tubing diameter: 1/4 inch
• Mounting thread: M5
• Fastening method: Internal hex (use allen wrench)
• No pipe tape or additional sealant is needed for fastening these fittings
• Pressure rating: 150 psi

This is a pneumatic push-to-connect union tee fitting. All three of the ports are push-to-connect 1/4" fittings.

Specifications:

• Weight: 0.02 pounds
• Width: 1.66"
• Height: 1.10"
• Depth: 0.525"
• Material: Plastic body
• Ports: 1/4" push-to-connect fitting
• Pressure range: 0-150 psi

This is a push-to-connect "Y" fitting.

Specifications:

• Weight: 0.02 lbs
• Width: 1.515 in
• Height: 0.56 in
• Depth: 1.31 in
• Material: plastic body material
• Ports: 1/4" push-to-connect fitting
• Pressure range: 0-150 psi

These double acting single rod stainless steel cylinders are a solid choice when you want air actuated motion. These cylinders have a strong 0.75 in. thick bore and are available in multiple stroke lengths.

Now, you can put your CKD valves on a light weight 4-bank aluminum manifold.

This is a hex nipple brass fitting, with one end being 1/4" NPT and the other being 1/8" NPT port. The intent of this part is to connect the air compressor (pump) to the aluminum manifold within the Pneumatics Base Kit.

Specifications:

• Weight: 0.05 pound
• Length: 1.15 inch
• Hex Width: 9/16 inch
• Material: Brass
• Ports: 1/4" NPT and 1/8" NPT
• Pressure range: 0-250 psi

This is an single solenoid, air-piloted, compact valve made by CKD. It's great for efficiently providing air to a small to medium sized actuator on mobile robots.

In order to make this work, you will also need three (3) M5 fittings (NOT INCLUDED) and some tubing (also NOT INCLUDED).

Link to CKD valve catalog

CKD part number: 4GA110R-M5-4

Specifications

• Cable Length: 3ft
• Flow Rate: 0.3 Cv
• Manufacturer: CKD
• Manufacturer Part #: 4GA110-M5-4
• Maximum Pressure: 125 psi
• Port(s): M5
• Voltage: 12Vdc
• Weight: 0.1 Lbs
• Width: 12mm

This is an double solenoid, air-piloted, compact valve made by CKD. It's great for efficiently providing air to a small to medium sized actuator on mobile robots.

In order to make this work, you will also need three (3) M5 fittings (NOT INCLUDED) and some tubing (also NOT INCLUDED).

Link to CKD valve catalog

CKD part number: 4GA120R-M5-4

Specifications

• Cable Length: 3ft
• Flow Rate: 0.3 Cv
• Manufacturer: CKD
• Manufacturer Part #: 4GA120-M5-4
• Maximum Pressure: 125 psi
• Port(s): M5
• Voltage: 12Vdc
• Weight: 0.14 Lbs
• Width: 12mm

This is an air pressure switch with a factory preset setting of 115-120 psi. This switch is able to send a signal to a robot controller, which can then tell a pneumatic compressor (air pump) to stop operating.

Specifications

• Circuit: SPST-NC
• Current Rating: 5 amps @ 30 VDC
• Cycle Life: 1 million
• Fixed set point: 115 psi
• Manufacturer: Nason
• Manufacturer Part #: SM-2B-115R/443
• Maximum Operating Pressure: 250 psi
• NEMA Rating: NEMA 4, 13
• Port(s): 1/8 in. NPT Male
• Screw Terminals: #8-32
• Set Point Direction: Rising

Documents

Guide(s)

am-2006 Data Sheet.pdf

This is a brass relief valve used in low-volume air tanks and pumps to retard excessive pressure buildup.

Specifications:

• Weight: 0.11 lbs
• Maximum operating pressure: 300 psi
• Outlet pressure adjustment: 70-150 psi
• Material: brass and stainless steel
• Manufacturer: Norgren
• Part Number: 16-004-011
• Operating temperature range: -30 to 200 degrees F
• Port size: 1/4" NPT
