Climber in a Box Brace Upgrade Kits - 1.5 in. Extrusion (1 Stage)

This is a package of FOUR stick-on numbers, designed to be adhered to robot bumper material.

Specifications:

• Quantity: 4
• Material: White stick-on plastic
• Height: 4 inches
• Width: 2.6 inches
• Line width: 0.8 inch
• Weight: 0.004 pounds

Usage (for best application):

• Apply heat to cloth area using a heat gun or hairdryer for 30 seconds (prior to placing number). Do not put heat on or near pool noodles, as they will shrink.
• Place numbers in position on bumper material as desired with pressure.
• Apply heat to numbers using a heat gun or hairdryer for 30 seconds.
• Place under a static load for 5 minutes.

This is a package of FOUR stick-on numbers, designed to be adhered to robot bumper material.

Specifications:

• Quantity: 4
• Material: White stick-on plastic
• Height: 4 inches
• Width: 2.6 inches
• Line width: 0.8 inch
• Weight: 0.004 pounds

Usage (for best application):

• Apply heat to cloth area using a heat gun or hairdryer for 30 seconds (prior to placing number). Do not put heat on or near pool noodles, as they will shrink.
• Place numbers in position on bumper material as desired with pressure.
• Apply heat to numbers using a heat gun or hairdryer for 30 seconds.
• Place under a static load for 5 minutes.

This is a package of FOUR stick-on numbers, designed to be adhered to robot bumper material.

Specifications:

• Quantity: 4
• Material: White stick-on plastic
• Height: 4 inches
• Width: 2.6 inches
• Line width: 0.8 inch
• Weight: 0.004 pounds

Usage (for best application):

• Apply heat to cloth area using a heat gun or hairdryer for 30 seconds (prior to placing number). Do not put heat on or near pool noodles, as they will shrink.
• Place numbers in position on bumper material as desired with pressure.
• Apply heat to numbers using a heat gun or hairdryer for 30 seconds.
• Place under a static load for 5 minutes.

This is a package of FOUR stick-on numbers, designed to be adhered to robot bumper material.

Specifications:

• Quantity: 4
• Material: White stick-on plastic
• Height: 4 inches
• Width: 2.6 inches
• Line width: 0.8 inch
• Weight: 0.004 pounds

Usage (for best application):

• Apply heat to cloth area using a heat gun or hairdryer for 30 seconds (prior to placing number). Do not put heat on or near pool noodles, as they will shrink.
• Place numbers in position on bumper material as desired with pressure.
• Apply heat to numbers using a heat gun or hairdryer for 30 seconds.
• Place under a static load for 5 minutes.

BLUE Cordura nylon bumper material. Each piece is 161 x 19.5 inches, enough to cover the entire perimeter of your FRC robot. The material is heavy-duty nylon cloth, much like the material used on backpacks.

Additional Information:


We also have stick-on numbers available (not included with material).

Specifications

• Color: Blue
• Denier: 1000
• Length: 161 in.
• Material: Nylon
• Width: 19.5 in.

RED Cordura nylon bumper fabric material. Each piece is 161 x 19.5 inches, enough to cover the entire perimeter of your FRC robot. The material is heavy-duty nylon cloth, much like the material used on backpacks.



Additional Information:


We also have stick-on numbers available (not included with the material).

Specifications

• Color: Red
• Denier: 1000
• Length: 161 in.
• Material: Nylon
• Width: 19.5 in.

This 6 in. long cable is designed specifically for the 2x5 pin data port on the Talon SRX to provide external inputs. It can be used to connect the Talon SRX to feedback devices such as potentiometers, limit switches, analog & quadrature encoders as well as providing other future expansions options beyond what is currently supported.

This cable can be used with the following list of products:

• Talon Tach (am-3778)
• Talon SRX Encoder Breakout Board (am-2633)
• Talon SRX Analog Breakout Board (am-2634)
• SPARK MAX Brushless and Brushed DC Motor Controller (am-4261)
• Lamprey Absolute Encoder (am-4179)
• SRX Magnetic Encoder (am-3445)

The AndyMark Climber in a Box is a robust, lightweight, configurable and affordable solution for climbing challenges historically present in FRC end game periods. The design of Climber in a Box has been inspired by many team designs along the way including 254 and 2056. The final prototype for this climber was developed in partnership with FRC Team 3940 CyberTooth for the 2020/2021 Infinite Recharge season. This mechanism has been battle tested with hundreds of climbs on a full weight FRC Robot without failures, both in development and real match play. Available in single and two stage configurations, this product should help teams of all levels elevate their team's performance at competitions.

This product uses a "spring out, winch back" powertrain strategy, using off-the-shelf 3.5lb constant force springs to raise the included Hook Kit, and 3mm Dyneema Rope to retract it with the included Winch Kit. Simply unspool the included rope using a planetary gearbox to raise the hook(s), drive the robot up to the bar, and winch it back to elevate your robot. The AndyMark Climber in a Box does not include a motor or gearbox, but is compatible with many off-the-shelf planetary gearboxes on the market that have a 2" bolt circle mounting pattern and support a 2" long 1/2" hex output shaft, including the highly durable blue Sport Gearboxes.

The bearing kits within this product are designed to go from 2" square 1/16" wall aluminum tubing, down to a 1" square 1/16" wall tube, with a 1.5" square 1/16" wall tube in between for the 2 stage flavor of this product. A combination of durable 608 bearings and custom molded plastic components provide the bearing surfaces for a free-flowing telescoping tube mechanism with no 3D printed parts. Each stage has a maximum travel of 24.5."

The AndyMark Climber in a Box is an unassembled kit of everything you need (besides a gearmotor) that is designed to not require any precision machining in order to make your FRC robot climb. The plates included within the Hook Kit, Bearing Kits and Winch Kit are all designed to be assembled and used as drill guides for match drilling their mounting locations onto the aluminum tubes. Each tube is pre-cut to a 30" length so no cutting of the tubes is required to achieve maximum travel.

Watch the teaser video here
