    Common Welding Joints Kit

    Use the curriculum and models in our Common Welding Joints Kit to teach students how to identify the most common welding joints. Each 10-piece kit includes both SMAW and GMAW coupon examples made of lightweight plastic. The included flashcards and curriculum address joint types, proper welding techniques and how to prevent welding issues.

    MFR Part #: 53010100
    Request a Quote

    Common Welding Joints Kit

    Welding Joints:

    • Butt Joint
    • Groove Joint - MIG (2 pass)
    • Groove Joint - STICK (2 pass)
    • Butt Joint - Square Butt/Groove (tack only)
    • Groove Joint - Single V Groove (tack only)
    • Tee Joint
    • Lap Joint
    • 6-inch Pipe
    • Intermittent weld: 2/side Length & Pitch
    • Intermittent weld: 3/side Length & Pitch

    Lesson topics:
    1. Common Welding Positioning
    2. Identifying Common Welding Joints



    Teaching hours: 1-2
    Includes: Presentation slides and student activities



    Write your own review
    • Product can be reviewed only after purchasing it
    • Only registered users can write reviews
    *
    *
    • Bad
    • Excellent

    Common Welding Joints Kit

    Welding Joints:

    • Butt Joint
    • Groove Joint - MIG (2 pass)
    • Groove Joint - STICK (2 pass)
    • Butt Joint - Square Butt/Groove (tack only)
    • Groove Joint - Single V Groove (tack only)
    • Tee Joint
    • Lap Joint
    • 6-inch Pipe
    • Intermittent weld: 2/side Length & Pitch
    • Intermittent weld: 3/side Length & Pitch

    Lesson topics:
    1. Common Welding Positioning
    2. Identifying Common Welding Joints



    Teaching hours: 1-2
    Includes: Presentation slides and student activities
