FIRST Tech Challenge INTO THE DEEP Full Game Set

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

Specifications

• Drive: 5/32 in. Hex
• Finish: Zinc
• Head: Socket Cap
• Length: 1.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.02 lbs

This item can only be purchased in multiples of 10

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 10-32
• Length: 1-3/4"
• Head: Socket Head Cap Screw

Used with Lego education Storage boxes # 9840, # 45498, and # 45497

This is the cable designed for the encoder that is pre-attached to the NeveRest Series of motors and gearmotors. It has a connector on the opposite end to directly interface with the REV Expansion Hub or the REV Control Hub.

2019 Update:

The 'a' version of this cable as the encoder channels swapped so that the encoder counts in the same direction as the output shaft spins. This simplifies the usage of the encoder with the various programming languages for FTC!

Specifications

• Length: 20 in.

These aluminum box extrusions are robust and lightweight solutions for custom robot frames, superstructures and mechanism construction. Made to all of your favorite English sizes, the classic 2x1 thin wall tubing is now joined by its thicker-walled counterpart. We have also introduced two thicknesses of 1x1 sizes that teams know and love to build their medium-sized mechanisms.

For smaller mechanisms, we recommend using our 5/8 square box tube that is also compatible with the S3 line of brackets and gussets.



Available Sizes:

• 2 x 1 x 1/16 in. (0.063 in.) 6061-T6 alloy
• 2 x 1 x 1/8 in. (0.125 in.) 6061-T6 alloy
• 1 x 1 x 1/16 in. (0.063 in.)6061-T6 alloy
• 1 x 1 x 1/8 in. (0.125 in.)6061-T6 alloy
• 5/8 x 5/8 x 1/16 in. (0.063 in.) 6061-T6 alloy
• All lengths are (+/- 1in)

Be sure to all check out our Gussets as they work wonderfully with all of these wonderful extrusions.

New for the 2024-2025 Season

Download the Kit List FTC Starter Kit 2024-2025.


This kit does not include any control system components.

#25 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #25
• Pitch: 0.250 inch
• Weight: 0.01 lbs

Each hub now has a "flower" pattern that fits and keys into our 42T 5 mm HTD Pulley, which means you are no longer constrained to our legacy 500EX Hex Hub for compatibility with this pulley. Every hub still maintains a closed-profile hole for maximum strength. Every shaft hub has been designed with bearing bosses on both sides that have been sized appropriately for the mating bearings that would pair with the bore through the hub, which means you can run each hub right against a bearing with no need for extra spacers. All of these hubs are also made from 7075-T6 aluminum, which is much stronger than the previously used 6061-T6, 6005, and 6105 alloys from our older designs. Where possible, the shoulder on shaft hubs was reduced to 7/8" in diameter for an easier fit with our molded plastic wheels, while still maintaining a precise 1.125" diameter boss for locating in wheels, sprockets, gears, and more.

The holes are evenly spaced on a 1.875 in. circle and 0.201 inches in diameter. That's a perfect size for #10 bolts!

Learn how to attach these hubs to AndyMark wheels by watching this video!

The D-Shaft Collar is 6mm ID and 12mm OD. The inside diameter will fit any of the D-Shaft axels.

Specifcations:

• Material: 6061-T6 Aluminum

• Step File
