Fitting, pneumatic, straight Y, 1/4 press-in

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 10-32
• Length: 5/8 inch
• Head: Socket Head Cap Screw
• Yellow Nylon Thread Lock Patch

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 1/4-20
• Length: 1/2"
• Head: Button Head Cap Screw

Made from aluminum and anodized in blue, the Studica 42mm Hinge with Bearings connects to the Studica structure hole pattern such as the channel, plates, and beams. The holes are 3.2mm diameter to use with the M3 screws.

• Material: 6063 Aluminum
• Length: 42mm
• Width: 30.88mm
• Thickness: 3.5mm
• Hole diameter: 3.2MM
• Step file

Pneumatic fitting with M5 threads and 1/4" push-in tubing port

This fitting screws into a CKD single or double solenoid valve.

Specifications:

• Pisco fitting, part number POC1/4-M5
• Tubing diameter: 1/4 inch
• Mounting thread: M5
• Fastening method: Internal hex (use allen wrench)
• No pipe tape or additional sealant is needed for fastening these fittings
• Pressure rating: 150 psi

This is a pneumatic push-to-connect union tee fitting. All three of the ports are push-to-connect 1/4" fittings.

Specifications:

• Weight: 0.02 pounds
• Width: 1.66"
• Height: 1.10"
• Depth: 0.525"
• Material: Plastic body
• Ports: 1/4" push-to-connect fitting
• Pressure range: 0-150 psi

Here is a packet of red tacky grease used to lubricate gearboxes. This grease sticks well to gears and does not sling off as the gears spin. Although it looks like raspberry jam, don't put it on your churro!

Specifications:

• Weight: 14.2 grams
• Package size: 2"x 5"

These connecting chain attachment links, also known as K-links, are perfect for securing components that need movement, to a chain. These versions were specifically designed by AndyMark to interface with common FRC and FTC products. The #35 chain version is designed for #10 hardware on a 1 on. hole spacing. The #25 chain version is designed for #6 hardware with 16 mm (5/8 in.) hole spacing. Both versions make it much easier to interface chain to elevator systems than ever before. They can also be used in conveyor systems to move items around inside your robot.

Specifications

• Chain Size: #25, #35
• Hole Size: #25: 0.150 in., #35: 0.201 in.
• Hole Spacing: #25: 16 mm, #35: 1.00 in.
• Load Capacity : #25: 150lb, #35: 300lb
• Material: Steel
• Pitch: #25: 0.250 in., #35: 0.375 in.
• Weight: 0.01 lbs

Documents

Layout Print(s)

am-4181_25 25 Chain Attachment Link.PDF

am-4181_35 35 Chain Attachment Link.PDF

CAD File(s)

am-4181_35 35 Chain Attachment Link.STEP

am-4181_25 25 Chain Attachment Link.STEP

These connecting chain attachment links, also known as K-links, are perfect for securing components that need movement, to a chain. These versions were specifically designed by AndyMark to interface with common FRC and FTC products. The #35 chain version is designed for #10 hardware on a 1 on. hole spacing. The #25 chain version is designed for #6 hardware with 16 mm (5/8 in.) hole spacing. Both versions make it much easier to interface chain to elevator systems than ever before. They can also be used in conveyor systems to move items around inside your robot.

Specifications

• Chain Size: #25, #35
• Hole Size: #25: 0.150 in., #35: 0.201 in.
• Hole Spacing: #25: 16 mm, #35: 1.00 in.
• Load Capacity : #25: 150lb, #35: 300lb
• Material: Steel
• Pitch: #25: 0.250 in., #35: 0.375 in.
• Weight: 0.01 lbs

Documents

Layout Print(s)

am-4181_25 25 Chain Attachment Link.PDF

am-4181_35 35 Chain Attachment Link.PDF

CAD File(s)

am-4181_35 35 Chain Attachment Link.STEP

am-4181_25 25 Chain Attachment Link.STEP

Anderson Power Products Connector with 2 contacts.

Specifications:

• Material (APP Connector): Red Plastic
• Weight: 0.060
• Mounting holes: 0.15" diameter, 3/4" apart

Included Hardware:

• One - SB-50A red plastic connector
• Two - Anderson Power Products crimp contacts (sized for 6 gauge wire)
