We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.
On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.
am-3860 90 Gusset REV2.PDF
am-4158 1IN Tee Gusset.PDF
am-4159 1IN Quad Gusset.PDF
am-4160 1IN 30deg Gusset.PDF
am-4161 1in 45deg Gusset.PDF
am-4162 1in 60deg Gusset.PDF
am-4163 1in 120deg Gusset.PDF
am-4164 1in 135deg Gusset.PDF
am-4165 1in 150deg Gusset.PDF
am-4166 1IN Sport Double Bearing Mount.PDF
am-4167 1IN 57Sport Side Mount Gusset.PDF
am-4168 1IN Bearing Side Mount Gusset.PDF
am-3860 90 Gusset REV2.STEP
am-4158 1IN Tee Gusset.STEP
am-4159 1IN Quad Gusset.STEP
am-4160 1IN 30deg Gusset.STEP
am-4161 1in 45deg Gusset.STEP
am-4162 1in 60deg Gusset.STEP
am-4163 1in 120deg Gusset.STEP
am-4164 1in 135deg Gusset.STEP
am-4165 1in 150deg Gusset.STEP
am-4166 1IN Sport Double Bearing Mount.STEP
am-4167 1IN 57Sport Side Mount Gusset.STEP
am-4168 1IN Bearing Side Mount Gusset.STEP
Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.
Made of aluminum, the Studica Clamping Shaft Hub is used with flex and drive wheels
May be used with 6mm D-Shape Shaft to secure wheels in their position.
The Studica End Piece Plate is commonly fastened to the inside end of the U Channel. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.
GT2-6mm Smooth Idler Pulley, H Type, w/3mm Inner Bore Bearing
The Studica Slide Rail is made of light weight aluminum, is 24mm wide, and is perfect for building a multi-stage slide system. Closed length is 384m, with a 240mm stroke, creating a 530mm extended length.
The M3 x 10mm Low Profile Screw with Kep Nut is a 304 Stainless Steel m3 Din 7991 Countersunk Hex Socket Flat Head Screw with a matching Kep Nut. This package is made for the Slide Rail, 288mm Length, 180mm Stroke and the Slide Rail, 384mm Length, 240mm Stroke
M3 x 8mm Socket Head Cap Screw (pack of 100), Zinc Plated.
M3 x 10mm Socket Head Cap Screw (pack of 100), Zinc Plated.
M3 x 12mm Socket Head Cap Screw (pack of 100), Zinc Plated.
M3 x 10mm Button Head Cap Screw (pack of 50), Zinc Plated.
M3 x 30mm Socket Head Cap Screw (pack of 50), Zinc Plated.
M3 x 20mm Socket Head Cap Screw (pack of 50), Zinc Plated.
Spare sets screws for Studica Robotics Hubs and Collars
10 Pack CONE HEX SOCKET SET SCREW DIN 914 M3 Thread
Spare sets screws for Studica Gears Including:
76219 - 30 Tooth Bevel Gear
10 Pack CONE HEX SOCKET SET SCREW DIN 914 M4 Thread
Spare sets screws for Studica Robotics Hubs and Collars and Gears
