0.375 in. ID 0.5 in. OD Aluminum Spacer at Various Lengths (1.1875 in)

This item can only be purchased in multiples of 25

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: #10-32
• Thickness: 0.249"
• Thread: Fine
• Thread Size: 32
• Type: Nylon Insert Lock Nut
• Wrench Size: 3/8"

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

This item can only be purchased in multiples of 25

#10-32 x 0.5 in. long Socket Head Cap Screw

Specifications

• Finish: Zinc
• Head: Socket Cap
• Length: 0.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.1 lbs

This 0.5 in. long 8-32 Button Head Cap Screw is used on the end of a Falcon 500 motor to retain pinions, adapters, or other spline hardware. It is included with the Falcon 500 Spline to 1/2 inch Hex Shaft Adapter.

Specifications

• Drive: 3/32 in.
• Finish: Black Oxide
• Head: Button Cap
• Length: 0.5 in.
• Material: Alloy Steel
• Thread: 8-32
• Weight: 0.006 lbs

Compliant wheels are not intended for moving robots, but moving objects. Compliant wheels give way to allow rigid objects to be manipulated easily. A line of multiple wheels on a driven hex shaft creates a very effective roller that ignores variations in the objects being driven. This makes for high-performance intakes and internal conveyors. The wheels are sized for an interference fit and tend to stay in place on a shaft, though a shaft collar may be used to make absolutely sure the wheels stay clear of other mechanisms or maintain consistent spacing.

The hex bore versions of this wheel are undersized, and are intended to be an interference fit on their respective hex shafts. This interference fit allows for effective torque transfer from the hex shaft to the wheel, as well as allowing the wheel to remain in place along the shaft without the need for spacers or collar clamps:

Different durometer ratings give each wheel unique characteristics. Green wheels (35A durometer) are the softest and most compliant around objects, while orange (40A), maroon (45A), and blue (50A) wheels are increasingly firm. The increased firmness also allows the latter wheels to carry a higher RPM rating. Check out the downloads tab for a chart showing wheels and their maximum RPM.

Specifications

• Bore: 1/2 in. Hex, 3/8 in. Hex, Nub Bore
• Diameter: 2 in.
• Durometer: 35A (Green), ⠀40A (Orange), ⠀45A (Maroon), ⠀50A (Blue), 60A (Black)
• Hole Pattern: Qty 2 3.5 mm Holes on a 16 mm Circle for 8 mm bore wheels
• Material: TPU
• Maximum RPM: 6000 - 9000
• Weight: 0.035 lb.
• Width: 0.5 in.

Documents

Layout Print(s)

am-3571 2IN 375 Hex Compliant Wheel REV3.PDF

am-3462 2IN 500Hex Compliant Wheel REV3.PDF

am-3572 2IN 8mm Compliant Wheel REV4.PDF

CAD File(s)

am-3571 2IN 375Hex Compliant Wheel REV2.STEP

am-3572 2IN 8mm Compliant Wheel REV2.STEP

am-3462 2IN Molded 500Hex Compliant Wheel REV2.STEP

Additional File(s)

2 inch Compliant Wheel Expansion.pdf

Don't see what you need?

Our Entrapption Stars have two bore options, making them viable parts for both FRC and FTC! This product is frequently used as intake wheels for picking up game pieces. Made from silicone, they are flexible, yet firm, allowing for the ability to pick up objects of irregular shape.

The 1/2 in. Hex Bore option is designed to be an interference fit on any 0.5 in. Hex Shaft.  This means the bore is actually 0.425 in. and it will be a tight press on, but keep the entrapption star from rotating.

3/8" Hex Bore, Shielded, Flanged Ball Bearing with Large (1.125") Outside Diameter

Specifications:

• inside diameter: 0.375-0.376 inch hex bore
• outside diameter: 1.125 inch
• overall thickness: 0.312 inch
• flange thickness: 0.055 inch
• Weight: 0.056 pounds

This novel style of collar clamp is split into two pieces so that it can be attached without removing any shafts. The bore is a 1/2" hex. The flats on the perimeter allow for the collar clamp to be held in position or turned for better assembly control.

This clamp has been designed and fabricated by BaneBots, and proudly sold through AndyMark.

Specifications:

• Material: Aluminum
• Bore: hex hole, 1/2 inch
• Outside Diameter: 0.94 inch
• Thickness: 0.375 inch
• Width Across Flats: 7/8 inch
• Weight: 0.020 pound
• Clamping Screws: #6-32 x 1/2" long (qty. 2)

Plastic spacers are included with this clamp, positioned between the two halves. These are to be removed before usage.

This simple bracket handles so many of your mounting needs! Mount motors or gearboxes anywhere and make axle supports with bearings - it's a do-it-all, put-it-anywhere bearing and motor mount bracket.

Any motor or gearbox with a 2-inch diameter bolt circle can be mounted in this bracket. The center hole is sized to hold a standard 1.125 inch outside diameter bearing.

Examples of motors with a 2 in. diameter bolt circle:

• 2.5 in. CIM Motor
• NEO Brushless Motor

Examples of gearboxes with a 2 in. diameter bolt circle

• PG Series Gearboxes
• 57 Sport Gearbox
• CIM Sport Gearbox
• Falcon Sport Gearbox
• DeCIMate Gearbox

Specifications

• Depth: 1 in.
• Height: 2.679 in.
• Length: 3.5 in.
• Material: 5052 Aluminum
• Thickness: 0.13 in.
• Weight: 0.104 lbs

Documents

Layout Print(s)

am-4244 1IN Pitch Bent Motor and Bearing Bracket REV2.PDF

CAD File(s)

am-4244 1IN Bent Bearing Side Mount Gusset.STEP
