192mm Flat Beam

This bushing fits into any 8mm hole such as those seen on tubing in the S3 Ecosystem. The bushing supports a 6mm shaft allowing you to use our precision 6mm D Shafts with the S3 Ecosystem and other systems.

Specifications:

• Inner Diameter: 6mm (0.24 in.)
• Outer Diammeter: 8mm (0.31 in.)
• Overall Length: 6mm (0.24 in.)

The Studica Flat Beam is 3mm thick and 8mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 8mm
• Length - 144mm
• Step File

The Studica Square Beam is 8mm by 8mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material -  Anodized 6061-T6 Aluminum
• Holes - 3.5mm diameter spaced 8mm apart
• Length - 144mm
<
• Step File

The Studica Flat Bracket is a very strong  3mm x 40mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 40mm
• Length - 96mm
• Step File

The Studica L-Beam is available in 9 different lengths from 48mm to 432mm. It is strong while light weight. It can be easily cut to your own custom size. The hole pattern matches the hole patterns in the Studica U-Channel, Low Profile U-Channel, and the various plates.

Specifcations,

• Material:  6061-T6 Aluminum
• Length: 336mm
• Width: 14mm
• Height: 14mm
• Thickness: 3mm
• Hole Diameter: 3.5mm
• Weight: 0.06kg
• Step File

The Studica 192mm x 96mm Flat Bracket is a very strong  3mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material - Anodized 6061-T6 Aluminum
• Thickness - 3mm
• Width - 96mm
• Length - 192mm
• Step File

This 20 Amp fuse is used in FIRST Tech Challenge batteries and the FIRST Robotics Competition Power Distribution Panel (am-2856).

Specifications:

• Color: Yellow
• Amps: 20
• Max Voltage: 32
• Style: MINI®
• Specification: SAE J2077
• Type: Blade Fuse

Use this 10-cell, 12-volt rechargeable pack to bring long-lasting power to TETRIX^® motors and electronics. This 3,000 mAh NiMH pack features a built-in, 20-amp replaceable fuse for safety.

(THIS BATTERY IS FTC LEGAL)

The Studica Square Beam is 8mm by 8mm. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material -  Anodized 6061-T6 Aluminum
• Holes - 3.5mm diameter spaced 8mm apart
• Length - 336mm
• Step File

This is the cable designed for the encoder that is pre-attached to the NeveRest Series of motors and gearmotors. It has a connector on the opposite end to directly interface with the REV Expansion Hub or the REV Control Hub.

2019 Update:

The 'a' version of this cable as the encoder channels swapped so that the encoder counts in the same direction as the output shaft spins. This simplifies the usage of the encoder with the various programming languages for FTC!

Specifications

• Length: 20 in.
