35 Series Symmetrical Hub Sprockets 500Hex, 10 Tooth

The 25 Series Plate Sprockets: They roll! They turn! They spin! Everything you could possibly want from a plate sprocket.

These Aluminum sprockets work perfectly with hex shaft and mesh with #25 roller chain.

These custom designed collar clamps have been designed specifically with FIRST Robotics Competition teams in mind. The one-piece collar clamp is a nice fractional 1/2 in. width to make shaft stackups easy. The clamping force is provided by a 10-32 socket head screw, which is bigger than most used in the competition marketplace.  This provides a high-strength clamping solution that shouldn't strip out when you need it most. You can even replace the 10-32 screw if it becomes lost with the screws historically used in the AM14U family of chassis. These thoughtfully designed collar clamps also have small bosses on each side. This allows these collar clamps to be installed directly adjacent to an FR8ZZ Round or FR8ZZ Hex bearing without rubbing on the outer races for smooth operation.

This is a 1/2 in. hex bore bearing that is shielded. This Ball Bearing is a great way to make things spin fast!

These aluminum box extrusions are robust and lightweight solutions for custom robot frames, superstructures and mechanism construction. Made to all of your favorite English sizes, the classic 2x1 thin wall tubing is now joined by its thicker-walled counterpart. We have also introduced two thicknesses of 1x1 sizes that teams know and love to build their medium-sized mechanisms.

For smaller mechanisms, we recommend using our 5/8 square box tube that is also compatible with our S3 line of brackets and gussets.

Available Sizes:

• 2 x 1 x 1/16 in. (0.063 in.) 6061-T6 alloy
• 2 x 1 x 1/8 in. (0.125 in.) 6061-T6 alloy
• 1 x 1 x 1/16 in. (0.063 in.)6061-T6 alloy
• 1 x 1 x 1/8 in. (0.125 in.)6061-T6 alloy
• 5/8 x 5/8 x 1/16 in. (0.063 in.) 6061-T6 alloy
• All lengths are (+/- 1in)

Be sure to all check out our Gussets as they work wonderfully with all of these wonderful extrusions.

Specifications

• Material: Aluminum

Documents

Layout Print(s)

am-3214 2x1x0625 6061-T6 wall tubing.PDF

am-4203 1x1x063 wall tubing.PDF

am-4204 1x1x0.125 wall tubing.PDF

am-4205 2x1x0.125 wall tubing.PDF

CAD File(s)

am-3214 2x1x0625 wall tubing.STEP

am-4203 1x1x0625 wall tubing.STEP

am-4204 1x1x0.125 wall tubing.STEP

am-4205 2x1x0.125 wall tubing.STEP

ON SALE

The REV NEO 550 Brushless Motor is the newest member in the NEO family of brushless motors. Its output power and small size are specifically designed to make NEO 550 the perfect motor for intakes and other non-drivetrain robot mechanisms. Mounting holes and pilot match a standard 550 series motor, making it natively mount to many existing off-the-shelf gearboxes.

FEATURES

• Mounting features match 550 series DC motors
• Out-runner construction
  • Rotor housing compatible with REV Motion Pattern - Mount metal Gears, Sprockets, and Pulleys
• Front and rear ball bearings
• High temperature neodymium magnets
• High-flex silicone motor wires
• Integrated motor sensor
  • 3-phase hall sensors
  • Motor temperature sensor

This spacer is made of aluminum and is 2 in. long. It is used in the Climber in a Box.

Specifications

• Inside Diameter: 0.192 in.
• Length: 2 in.
• Material: Aluminum
• Outside Diameter: 0.375 in.

A West Coast style drivetrain can be finicky to create without precision machining capabilities. This Bearing Block Kit makes it much more accessible for teams to create high performance West Coast Drive style platforms with limited fabrication resources. Simply drill a clearance hole for a shaft to pass through your drive rail, pull your chain or belt tight, and clamp it down with the included hardware. Featuring machined pockets to capture 10-32 Nylock Nuts, these blocks can be used and reused without worrying about damaging threads upon installation. Because each block is the same part, you can keep the screw heads pointing to the outside of your robot for easy maintenance.

This unassembled kit ships with enough hardware to provide significant clamping pressure to help keep your powertrain components tensioned properly, and can withstand upwards of 1500lbs of force along the axis of the tube when properly installed. This means that for most FRC use cases, a team can install these without the need for tensioning devices to keep things aligned.

The AndyMark West Coast Drive Bearing Block Kit is designed to be used with flanged ball bearings with a 1.125" outer race, such as our FR8ZZ-HexHD Bearing.

The AndyMark West Coast Drive Bearing Block Kit also includes mounting geometry for components that utilize 2" and 1.875" bolt circles, such as motors, gearboxes, sprockets, hubs and gears. This makes this product great for many uses outside of your drivetrain, such as a robust interface to make a rotary arm, or an easy-to-use mounting interface for motors to power your mechanisms. The bearing plate is also 2" wide, making it perfect to keep two 20DP gears (of which the total teeth add up to 80,) meshed together.

Items Included

• 2 - WCD Bearing Block (am-4560)
• 4 - 10-32 Nylock Nut (am-1042)
• 4 - 10-32 x 1.5in Socket Head Cap Screw (am-1014)

Specifications

• Block Height: 0.45 in.
• Block Length: 2.88 in.
• Block Material: Aluminum
• Block Width: 2.00 in.
• Weight: 0.33 lbs

Documents

Layout Print(s)

am-4576 WCD Bearing Block Kit.pdf

am-4560 WCD 1.125 Bearing Block REV 2.pdf

CAD File(s)

am-4576 WCD Bearing Block Kit.STEP

am-4560 2x1 WCD 1.125 Bearing Block REV2.STEP

These motor mounting kits attach various motor options to a sport gearbox. Each kit includes the correct pinion, plate, and mounting hardware to pair a Sport gearbox with your favourite motor.

Specifications:

• Bore: 0.500 in. Hex
• Series: #25
• Weight: 0.03 Pounds
• Material: 7075-T6 Aluminum
• Thickness: 0.1 in.
• Tooth Count: 18
• Hub Diameter: 0.873 in.
• Overall Depth: 0.4 in.
• Pitch Diameter: 1.440 in.
• Outside Diameter: 1.568 in.

The AndyMark Climber in a Box is a robust, lightweight, configurable and affordable solution for climbing challenges historically present in FRC end game periods. The design of Climber in a Box has been inspired by many team designs along the way including 254 and 2056. The final prototype for this climber was developed in partnership with FRC Team 3940 CyberTooth for the 2020/2021 Infinite Recharge season. This mechanism has been battle tested with hundreds of climbs on a full weight FRC Robot without failures, both in development and real match play. Available in single and two stage configurations, this product should help teams of all levels elevate their team's performance at competitions.

This product uses a "spring out, winch back" powertrain strategy, using off-the-shelf 3.5lb constant force springs to raise the included Hook Kit, and 3mm Dyneema Rope to retract it with the included Winch Kit. Simply unspool the included rope using a planetary gearbox to raise the hook(s), drive the robot up to the bar, and winch it back to elevate your robot. The AndyMark Climber in a Box does not include a motor or gearbox, but is compatible with many off-the-shelf planetary gearboxes on the market that have a 2" bolt circle mounting pattern and support a 2" long 1/2" hex output shaft, including the highly durable blue Sport Gearboxes.

The bearing kits within this product are designed to go from 2" square 1/16" wall aluminum tubing, down to a 1" square 1/16" wall tube, with a 1.5" square 1/16" wall tube in between for the 2 stage flavor of this product. A combination of durable 608 bearings and custom molded plastic components provide the bearing surfaces for a free-flowing telescoping tube mechanism with no 3D printed parts. Each stage has a maximum travel of 24.5."

The AndyMark Climber in a Box is an unassembled kit of everything you need (besides a gearmotor) that is designed to not require any precision machining in order to make your FRC robot climb. The plates included within the Hook Kit, Bearing Kits and Winch Kit are all designed to be assembled and used as drill guides for match drilling their mounting locations onto the aluminum tubes. Each tube is pre-cut to a 30" length so no cutting of the tubes is required to achieve maximum travel.
