400mm Linear Slide Set

May be used with 6mm D-Shape Shaft to secure wheels in their position.


Specifications:

• Φ20.0mm*8.0mm thick
• 1*M3 thread for M3 SHCS on the clamp side
• Φ6.0mm D hole
• AL6061-T6
• Step File

These gearboxes are designed with the same 37 mm diameter as the original 60:1 gearbox, while using the same 6 mm D-shaft and alignment pins, so getting the additional speed you need is a breeze.

Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.

Specifications:

• Material: Steel
• Number of teeth: 30
• Set of 2 for 1-1 drives
• Step File

The Studica Low Profile U Channel is 3mm thick and has a 48mm x 14mm profile. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Height - 14mm
• Width - 48mm
• Length - 432mm
• Hole pattern - 9
• Step File

The Motor Mount Plate is used with the Maverick 12V DC Gear Motor  (Part# 75001) to attach it inside the anyone of the U Channels 76010 to 76018. This is an example of a chassis with 4 motors mounted inside the U-Channel using a Motor Mounting Plate.

• Step File

This linear motion closed type slide unit has an 8 mm inside diameter. The slide unit, designed to carry a component, has a housing with a flat mounting face and four tapped bolt holes, and circle clips at each end to retain the ball bushing. Ball in the cage loop to run a smooth ball guide surface to ensure even if high-speed operation, low noise. Used with WSR Linear Motion Shaft - 8mm(D) x 496mm(L)

Features:

• Closed type bushing block and ball bushing insert for use in linear motion applications
• Four-bolt aluminum alloy bushing block for a lightweight ready-to-mount installation
• Synthetic resin retainer plate for accurate ball guidance and low noise
• Four rows of recirculating balls inside the ball bushing for smooth running
• Integral lip seals to retain lubricant and protect against contamination

This linear motion shaft of 8 mm in diameter and 496 mm in length is chrome plated and case hardened, and is suitable for use with slide units in linear motion applications. The high-carbon steel shaft is chrome plated for corrosion resistance, case hardened for wear resistance, and precision ground for consistent ball bushing radial clearance. Used with WSR Linear Motion Slide Unit 8mm(ID) -2 pack

Features:

• Round steel shaft for use with slide units in linear motion applications.
• Chrome plated for corrosion resistance
• Case hardened for wear resistance
• Precision ground for consistent ball bushing radial clearance

GT2-6mm Smooth Idler Pulley, H Type, w/3mm Inner Bore Bearing

The Studica Flat Bracket is a very strong  3mm x 40mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 40mm
• Length - 240mm
• Hole Pattern - 5
• Step File

The 250mm Rail and Block Set will provide precision and low friction sliding for all your robot applications.

Specifications:

• 9mm wide x 250mm Stainless Steel Guide Rail
• Ball Bearing Block
• Step File
