Battery Beak for FIRST Tech Challenge Batteries

The Studica Robotics 12V 30000mAh NiMH (nickel metal hydride) Battery Pack, PP45 - ARES in Black comes with a w/20 amp fuse. It is a 10-cell, 12-volt rechargeable battery pack.

The Studica Robotics NiMH Battery Pack Charger, PP45, is required to charge the battery.

THIS BATTERY IS FTC LEGAL

The Studica Flat Bracket is a very strong  3mm x 40mm wide. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Width - 40mm
• Length - 240mm
• Hole Pattern - 5
• Step File

Tip-to-tip length is approximately 12.6 inches.

The Motor Mount Plate is used with the Maverick 12V DC Gear Motor  (Part# 75001) to attach it inside the anyone of the U Channels 76010 to 76018. This is an example of a chassis with 4 motors mounted inside the U-Channel using a Motor Mounting Plate.

• Step File

FOR SALE TO CANADIAN TEAMS ONLY

This is the game piece for the 2024 FIRST® Robotics Competition CRESCENDO℠ presented by Haas. It has a 14 in. OD and a 10 in. ID and is rather squishy / flexible.

There are 113 total Notes on a field, 6 of which are “High Notes” that have white Gaff Tape (not included) applied as specified in the Game Manual.

The breakdown is:

• 45 in Red Player Station
• 45 in Blue Player Station
• 3 for pre-load in Red Robots
• 3 for pre-load in Blue Robots
• 5 in Center Field
• 3 in Red Alliance Starting Zone
• 3 in Blue Alliance Starting Zone
• 6 High Notes for Human Players

For optimal shipping efficiency please know that Notes ship from the manufacturer in boxes of 24 (but can be ordered in any quantity).

Specifications

• Inside Diameter: 10 in.
• Material: Coated Foam
• Outside Diameter: 14 in.
• Thickness: 2 in.
• Weight: 8.3 Oz +/- 1 Oz

With custom hubs, this offering from SDS has competition-tested performance combined with seamless integration into the MK4 and MK4i Swerve Modules.

Colson Performa Wheels have been used extensively in BattleBots and FIRST Robotics Competitions, and are widely lauded as an intelligent choice for swerve. The durable co-injection molded construction of a thermoplastic elastomer tread permanently bonded to a polyolefin core helps ensure the wheel can withstand the rigors of robot competitions while being friendlier to non-carpeted surfaces and providing a more consistent performance throughout the life of the wheel compared to roughtop tread.

The aluminum hub is secured to the bevel gear using three screws which captures the wheel. This setup provides a simplified replacement process for heavy use during competition season.

Included Components in am- 5173:

• 3 - Black Oxide 10-32 1 in. Long Cap Screw (Similar to am-1056)
• 1 - Hub
• 1 - Colson Wheel (am-5171)

Specifications

• Brand: SDS
• Diameter: 4 in.
• Width: 1.5 in.

Use the Motor Mount Clamp kit when fastening motors on body and attaching kit to channel and other structure.

• Step File Top
• Step File Bottom

Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.

Specifications:

• Material: Steel
• Number of teeth: 30
• Set of 2 for 1-1 drives
• Step File

With custom hubs, this offering from SDS has competition-tested performance combined with seamless integration into the MK4 and MK4i Swerve Modules.

Colson Performa Wheels have been used extensively in BattleBots and FIRST Robotics Competitions, and are widely lauded as an intelligent choice for swerve. The durable co-injection molded construction of a thermoplastic elastomer tread permanently bonded to a polyolefin core helps ensure the wheel can withstand the rigors of robot competitions while being friendlier to non-carpeted surfaces and providing a more consistent performance throughout the life of the wheel compared to roughtop tread.

The aluminum hub is secured to the bevel gear using three screws which captures the wheel. This setup provides a simplified replacement process for heavy use during competition season.

Included Components in am- 5173:

• 3 - Black Oxide 10-32 1 in. Long Cap Screw (Similar to am-1056)
• 1 - Hub
• 1 - Colson Wheel (am-5171)

Specifications

• Brand: SDS
• Diameter: 4 in.
• Width: 1.5 in.
