8mm to 1/2 in. Hex Shaft Adapter - Long
This adapter converts an 8 mm keyed shaft to 1/2 in. hex. The keyway is 2 mm wide. This allows you to adapt the output of a motor or gearbox like the CIM Motor (am-0255) to any of our hubs or wheels with a 1/2 in. hex bore. You'll need a 2 mm machine key (am-1121) to complete the assembly and transmit torque from the motor.
This adapter is no longer available in the 0.75 in. length.
Specifications
- Bore: 8 mm Round
- Keyway Width: 2 mm
- Length: 0.5 in., 1 in.
- Material: Steel
- Weight: 0.03 lbs
- Width: 0.497 - 0.499 in.
#10-32 x 0.625" SHCS - Min 25
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 10-32
- Length: 5/8 inch
- Head: Socket Head Cap Screw
- Yellow Nylon Thread Lock Patch
10-32 x 1.5 in. Socket Head Cap Screw
Specifications
- Drive: 5/32 in. Hex
- Finish: Zinc
- Head: Socket Cap
- Length: 1.5 in.
- Material: Steel
- Thread: 10-32
- Weight: 0.02 lbs
This item can only be purchased in multiples of 10
1/4-20 Nylock Nut
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 1/4-20
- Width across hex: 7/16"
This item can only be purchased in multiples of 25
1/4-20 x 1.5 in. Socket Head Cap Screw
Standard 1/4-20 Socket Head Cap Screw (SHCS) that's 1.5 in. long.
Specifications
- Drive: 3/16 in. Hex
- Head: Socket Cap
- Length: 1.5 in.
- Material : Steel
- Plating: Zinc
- Thread: 1/4-20
- Weight: 0.01 lbs
This item can only be purchased in multiples of 10
1/4-20 x 3 in. Socket Head Cap Screw
1/4-20 x 3" Long Socket Head Cap Screw
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 1/4-20
- Length: 3 inch
- Head: Socket Head Cap Screw
- Weight: 0.426 pounds
1 in. Tee Gusset
We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.
On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.
Specifications
- Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
- Material: 6061-T6 Aluminum
- Thickness: 0.125 in
2.5 inch CIM Motor
The CIM motor is a tried and true FIRST Robotics Competition workhorse motor. This brushed DC motor is 2.5 inches in diameter and kicks out 337 watts of power.
Pinion Options:
The CIM motor shaft is 0.313 in. (8 mm) in diameter and 1.25 inches long. It features a 2 mm wide machine key slot allowing installation of any number of custom or off the shelf pinions such as those included with all of our CIM based gearboxes. Other options include a pre-attached 16 tooth pinion making the CIM ready to mate to a CIM Sport planetary gearbox or a pre-attached 15 tooth pinion preparing the CIM for an EVO Gearbox. Use either of these two options if you are planning on using either the CIM Sport or an EVO gearbox and don't want to install the press fit pinion yourself. All of our other CIM based gearboxes use a slip fit pinion & machine key and are easy for the end user to install.
Compatible Components:
- Long CIM Motor Key - 2x2x14 mm Machine Key (am-0032)
- CIM Motor Key - 2x2x10 mm Machine Key, steel (am-1121)
- Retaining Ring for CIM Shaft - Retaining Clip, 8 mm id (am-0033)
Motor Etching
- Logo: AndyMark Logo
- Voltage and Name: 12VDC 2.5" CIM MOTOR
- CCL part number: PM25R-45F-1003
- Manufacturing date: MMDDYY
Specifications
- Bolt Pattern: 2 #10-32 Holes on a 2 in. diameter bolt circle
- Duty Cycle: Intermittent
- Free Current: 2.7 AMPs
- Free Speed: 5310 RPM
- Maximum Power: 337 Watts
- Output Shaft Diameter: 0.313 in. (8mm)
- Output Shaft Length: 1.245 in.
- Stall Current: 133 AMPs
- Stall Torque: 343.4 in-oz
- Voltage: 12 Volts DC
- Weight: 2.8 lbs
2x2x10 mm Machine Key, steel
Machine Key, steel. Used in 2.5" CIM Motor shafts.
Specifications:
- Width: 2mm (0.078 inch)
- Length: 10mm (0.394 inch)
- Weight: 0.0008 pounds
FTC Perimeter Field Kit
This is the official FIRST Tech Challenge Perimeter. This perimeter may be referenced as am-0481, am-0481a, or am-0481b in documentation. This is reusable from year to year and does not include soft tiles, game-specific hardware, components, or game pieces. This "b" revision is compatible with the previous "a" revision, meaning "b" version corners and panels can be used as replacement in "a" version perimeters.
The perimeter is comprised of eight hinged panels and four straight panels. Once assembled, the perimeter creates an 11 feet 9 inch by 11 feet 9 inch square enclosure. The hinged corners and quick release pins make for easy assembly, requiring no tools. Side panels include a built-in wire way for easy cable management.
An adjustable Perimeter Strap (am-2270a) placed under this playing surface help keep the walls square during game play.
Usually Ships in 2 to 3 Weeks
Included Hardware:
- 4 - Hinged Panel Corners (am-2600b)
- 4 - Flat Panel Sections (am-2160b)
- 2 - Straps with Hooks (am-2270a)
- 16 - Panel Rail Links (am-2580a)
- 32 - Panel Link Fastener Pins (am-2579)
FIRST Tech Challenge Premium Accessory Set
Here you can get all the components needed to setup the entire FTC perimeter. Save a bit of money and buy it as one package instead of each piece separately, carrying bags included!
roboRIO 2.0
NOTE: This product is not included in any Sales or Discounts.
The NI roboRIO 2.0 is new for the 2022 FIRST Robotics Competition. The most up to date information, and technical specifics, will be published by NI when they become available. For more roboRIO support for FIRST Robotics Competition teams, visit ni.com/frc
This device is designed specifically with FIRST in mind. The announcement of the roboRIO 2.0 on the FIRST Robotics Competition Blog, discusses all the new features to expect.
Performance Pneumatics Kit
This is the next step in a pneumatics package, which gives you all the parts you need for an entire system to push 7" stroke cylinders (included). And creates pressurized air in a safe, manageable manner for mobile robots.
Entire list of Hardware:
- One - Viair air compressor pump
- Two - 20 meters of Pneumatic tubing, 1/4" od, polyurethane, black
- Two - 574ml Plastic Air Tank
- Four - Bracket for mounting Air Tank
- Two - Valve, pneumatic, single solenoid, CKD 4GA110-M5-E01-4
- Two - Valve, pneumatic, double solenoid, CKD 4GA120-M5-E01-4
- Twelve - M5 Pisco Fitting for 1/4" press-in tube, POC1/4-M5
- Two - NCME075-0700 SMC Air Cylinder, 3/4" bore, 7" stroke
- One - Ball Valve, 1/4" NPT Male x Female, Lever Handle, Chrome Plated
- One - Norgren pressure regulator and bracket
- Two - Norgren pressure gauge
- One - Norgren pressure relief valve
- One - Nason pressure switch
- Seven - 1/4" NPT straight press-in fitting
- Thirteen - 1/8" NPT straight press-in fitting
- Five - Union Tee, 1/4" tube
- Two - 1/8 NPT Plug
- Four - 1/8 to 1/4 NPT Nipple
- Ten - 1/8" NPT flow control
- Three - Bulkhead fitting
- Thirteen - 1/8" NPT elbow press-in fitting
- Three - PTFE Tape Roll
- Five - 1/8" NPT Y fitting with 2 tubing ports
- Four - Stright Y, 1/4" Tube Press-In
- Two - 1/4 NPT Plug
- Two - Brass Y, 1/8" NPT, 2 Female, 1 Male
- Four - Brass Hex Nipple, 1/8" NPT
- Two - Brass Hex Nipple, 1/4" NPT
- Eight - Elbow, 1/4" Tube press-in, 1/4" NPT male
- Five - Valve, 1/8 NPT, 1/4 push-in fitting
- Three - 1/8" NPT cross fitting with 4 ports: 3 female and 1 male
- Three - 1/4" - 1/8" NPT adapter fitting
- Two - In-Line Flow Control, 1/4" Tube press-in
0.118 in. Thick 24 in. x 24 in. Polycarbonate Sheet
This is a single sheet of 1/8 inch thick polycarbonate (PC) plastic, cut to a 24x24 inch square. This single sheet of PC will be shipped with the protective covering on both sides of the plastic sheet.
Polycarbonate was invented in 1963 by Dan Fox at General Electric. GE's trade name for this plastic is LEXAN, but it also is sold under other trade names (Makrolon, Hyzod, Cyrolon).
This material is NOT plexiglas or acrylic, as we don't suggest that you use that material on a mobile robot, since acrylic will easily shatter.
Specifications:
- Weight: 2.9 pounds
- Width: 24 inches
- Length: 24 inches
- Material thickness: 0.118 inch
- Material: Clear Polycarbonate
Powerpole Kit 50 Red and Black Housings 100 Contacts
This is a kit of loose Anderson Power Products (APP) Powerpole (model PP45) connector hardware, aimed at providing a robot builder some tools to make dis-connectable cables and wires. This kit contains 50 Red Housings, 50 Black Housings and 100 Contacts.
This kit provides the connecting hardware needed to make 50 Ground/12V pairs that are easily removable.
The contacts are rated for 45 amps, and sized for 10-12 gauge wire. Use our Powerpole Crimper for good connection.
Included Hardware:
- Fifty - Red APP single-connector Powerpole housings (APP #: 1327)
- Fifty - Black APP single-connector Powerpole housings (APP #: 1327G6)
- One Hundred - Contacts (APP #: 261G2-LPBK)
- Overall weight - 0.44 lbs.
