Standard 32DP Gears (1/2 in Hex, Steel, 32 Tooth)

This Inline Chain Tensioner for #35 series roller chain is perfect to adjust the desired tension in a long run of chain on mechanisms such as elevators and arms. This is ideal where there is at least a ~3" section of chain that never passes over a sprocket in a given mechanism. Pair this with two #35 Master Links and integrate this to your robot for an easy-to-use chain tension solution!

The design of this product was inspired by Misumi's Chain Turnbuckles. This product has been improved to be compatible with imperial-sized wrenches.

Specifications

• Chain Size: #35

Documents

CAD File(s)

am-3914_35 35 Chain Tensioner.STEP

Layout Print(s)

am-3914_35 #35 Chain Inline Tensioner.PDF

Whether you have shafts that are too short or shafts of different types, this coupling will solve every component connection issue you've had! Need to combine multiple hex shafts, multiple 1/2-inch keyed shafts, or convert between hex and keyed? This coupling solves all at a better price than anyone else can offer!

Shaft Compatability

This coupling has geometry to capture 0.50-inch hex shafts with an inside hex of 0.51 to 0.52 inches as well as 0.5 inch keyed shafts with a 1/8th inch keyway with a keyway width of 0.128 inches to 0.131 inches.

Machine Key, steel

Specifications:

• Width: 3/16 inch (0.185-0.187)
• Length: 1 inch
• Weight: 0.01 pounds

This 4mm x 12mm machine key is intended to be used with PG71 Gearmotor (am-0914), PG71 Gearbox (am-0939), and 10mm Key Hub (am-0985) Specifications: Width: 4mm Length: 12mm Weight: 0.0018 pounds

The CIM Sport is a competition tested high performance line of planetary gearboxes from AndyMark and BaneBots. The CIM Sport features numerous improvements over previous planetary gearboxes used on FIRST Robotics Competition robots.

These connecting chain attachment links, also known as K-links, are perfect for securing components that need movement, to a chain. These versions were specifically designed by AndyMark to interface with common FRC and FTC products. The #35 chain version is designed for #10 hardware on a 1 on. hole spacing. The #25 chain version is designed for #6 hardware with 16 mm (5/8 in.) hole spacing. Both versions make it much easier to interface chain to elevator systems than ever before. They can also be used in conveyor systems to move items around inside your robot.

Specifications

• Chain Size: #25, #35
• Hole Size: #25: 0.150 in., #35: 0.201 in.
• Hole Spacing: #25: 16 mm, #35: 1.00 in.
• Load Capacity : #25: 150lb, #35: 300lb
• Material: Steel
• Pitch: #25: 0.250 in., #35: 0.375 in.
• Weight: 0.01 lbs

Documents

Layout Print(s)

am-4181_25 25 Chain Attachment Link.PDF

am-4181_35 35 Chain Attachment Link.PDF

CAD File(s)

am-4181_35 35 Chain Attachment Link.STEP

am-4181_25 25 Chain Attachment Link.STEP
