Description

Metric drag racing is an excellent way to motivate students while they design, construct, and race their own CO₂ dragsters. This Getting Started package includes everything you need to launch your students’ program: materials to build and finish 50 student dragsters.

Our illustrated, self-directed student workbook holds the students’ attention as they learn step-by-step automotive-design processes. The CO₂ Dragster User Guide is available for print here, or you can download a digital copy for free here.

This top-notch bike pump will stand up to years of use. It features all-metal construction and a heavy-duty rod that resists bending. Also features a mounted pressure gauge, a locking hose end, and a contoured, rubberized handle.

Pump shipped may not match picture.

All the metal and materials you’ll need to make a 13" long x 5" wide x 4" deep toolbox. Drawings included. Ideal for a first sheet metal project. Students can use the box for tools or tackle. Galvanized steel construction will not rust. Box may be left plain or painted. Requires 1/8" rivets; tools sold separately.

Tetrix Prime; Battery Mount Bracket makes it easy to mount battery packs to your robotic designs. Features two heavy-duty plastic clips that are used together with a bungee band to tie down the Tetrix Prime; Battery Pack. An extra band is included.

• Quantity: pkg of 2
• Material: ABS plastic
• Nominal Size: 70 mm x 16 mm x 23 mm
• Weight: 9.9 grams per bracket

Tetrix Prime Beam Attachment Hub can be used to attach a 6 mm shaft through an aluminum beam to form a pivot. Made of acetal plastic. Requires Tetrix Prime; Thumbscrews and Socket Head Cap Screws, sold separately.

• Weight: 6.9 grams per hub
• Quantity: pkg of 2
• Material: Molded acetal
• Nominal Size: 32 mm x 19 mm x 18 mm

Tetrix Prime Beam End Connectors are used to join a beam end to a beam side at a 90° angle. Made of acetal plastic; requires Quick Rivets and Pegs and a Thumbscrew (all sold separately).

• Weight: 3.6 grams per connector
• Quantity: pkg of 2
• Material: Molded acetal
• Nominal Size: 16 mm x 16 mm x 36 mm

Tetrix Prime Beam Extension Connectors bring together two square aluminum beams end to end without adding any space between. Made of ABS plastic; requires Quick Rivets and Pegs or Thumbscrews and Wing Nuts (all sold separately).

• Quantity: pkg of 2
• Material: ABS plastic
• Nominal Size: 13 mm x 17 mm x 64 mm
• Weight: 4.6 grams per connector

Tetrix Prime; Beam Straight Connectors connects two square aluminum beams end to end, adding one beam width in between. Made of ABS plastic; requires Quick Rivets and Pegs or Thumbscrews and Wing Nuts (all sold separately).

• Quantity: pkg of 2
• Material: ABS plastic
• Nominal Size: 16 mm x 16 mm x 80 mm
• Weight: 8 grams per connector

Tetrix Prime 6mm(ID) x 9mm(L) Bronze Bushings keep things running smoothly on your robotic creation. Sized for the Tetrix Prime; system, these 9 mm by 6 mm bronze bushings are lightly lubricated to reduce friction on axles.

• Weight: 1.4 grams per bushing
• Quantity: pkg of 12
• Material: SAE 841 Bronze
• Nominal Size: 9 mm OD x 6 mm ID x 9 mm L

The TETRIX PRIME Class Pack serves 12 teams of two students, offering each pair of students their own Tetrix Prime; R/C Starter Set to work with. Using the sets and the instructions from the included builder’s guide, students work collaboratively to engineer fully functioning, remote-controlled robots.

Includes:

• 12 Tetrix Prime; R/C Starter Sets each containing:
  • 298 building elements plus Gripper Kit
  • Gamepad-style, four-channel wireless controller
  • 4 servo motors (2 standard and 2 continuous rotation)
  • Rechargeable battery pack and charger
  • On/off switch and assembly tools
  • Printed setup and builder’s guides along with activity accessories

Great for when you’ve bought extra Tetrix Prime; parts and want uniform bins to store them in. Includes 11-1/8" x 17" lid.

This set includes everything you need for students to start building remote-controlled and autonomous-controlled robots with the TETRIX PRIME system.

Includes:

• TETRIX PULSE Robotics Controller with USB cable
• Grove Line Finder and Ultrasonic Sensors
• Gamepad-style, four-channel wireless controller for easy operation of the motors and servos
• 290+ Tetrix Prime; aluminum and plastic pieces including structural elements, connectors, hubs, brackets, wheels, and gears plus a Gripper Kit
• Rechargeable battery pack and charger
• 2 standard servos, 2 continuous rotation servos, and 2 six-volt DC motors
• On/off switch
• 4-in-1 screwdriver, 2-in-1 screwdriver, and hex nut driver
• Sturdy storage bin
• Balls and cups for robot course
• Detailed and graphic programming and builder’s guide

Expand the horizons of your TETRIX PRIME R/C Starter Set. Engineer bigger, more advanced robots, increase the robustness of builds, and combine all the Tetrix Prime; components using the additional parts and pieces included in the Tetrix Prime; Expansion Set.

The Tetrix Prime; Expansion Set comes with three major parts that will provide students more design options for their robots:

• Aluminum linkages – Mechanical linkages connect to manage force and movement.
• Aluminum plates – Create custom gearboxes, strengthen connections, or create new ways to connect and combine all the Tetrix Prime; components.
• Aluminum gussets – Use to connect beams or structural components as well as provide additional strength to joints.
• Tetrix Prime; parts and pieces are made from aluminum and plastic.

The TETRIX PRIME Getting Started Package offers the ultimate robotics experience. Teams of two work to design fully functioning, remote-controlled robots, with each student pair having access to both a Tetrix Prime; R/C Starter Set and a Tetrix Prime; Expansion Set. The included Instructional Build DVD for Tetrix Prime; Robotics and Engineering Design Loop Poster Set provide an added bonus to the builder’s guides.

The Getting Started Package includes:

• 12 Tetrix Prime; R/C Starter Sets each containing:
  • 298 building elements plus Gripper Kit
  • Gamepad-style, four-channel wireless controller
  • 4 servo motors (2 standard and 2 continuous rotation)
  • Rechargeable battery pack and charger
  • On/off switch and assembly tools
  • Printed setup and builder’s guides along with activity accessories
• 12 Tetrix Prime; Expansion Sets each containing:
  • 539 total building elements
  • 1 standard servo motor
  • Assembly tools
  • Printed builder’s guide
• Engineering Design Loop Poster Set
• Instructional Build DVD for Tetrix Prime; Robotics

Tetrix Prime Gripper Kit enables you to build a gripper for your Tetrix Prime; robot. After it is built, the gripper can easily be added to a robot, using a thumbscrew and wing nut. Gripper jaws open to 63 mm to pick up objects. Comes with necessary hardware and screws. Requires assembly and a standard servo, sold separately.

• Weight: 33.9 per gripper
