SB-50A Anderson Powerpole Connector with Contacts

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

0.1 in. - spaced connectors commonly used as the PWM (Pulse Width Modulation) Connectors on mobile robots and a simple controls method for many speed controllers.

25 crimp connector housings that would hold 3 pins at a 0.1 in. spacing are included as well as 100 FEMALE Pins that would be crimped on 22-28 AWG wires and snapped into the crimp connector housings.

Be sure to get a proper PWM crimp connector to be sure your connections are tight.

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 10-32
• Length: 5/8 inch
• Head: Socket Head Cap Screw
• Yellow Nylon Thread Lock Patch

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 1/4-20
• Length: 1/2"
• Head: Button Head Cap Screw

This is a quick and reliable compact connector for flexible conductors. Splicing has never been easier. Lift the orange lever, and insert the conductor, close the lever. The lever clicks as it is lowered, actuating the CAGE CLAMP®, for superior connectivity. This tool-free connection and disconnection makes the connection simple to create and alter in the future.

errules are crimped on the metal contact rather than through the insulation like standard connectors. This means there is more contact between the wire strands and the contact point. This Ferrule can be crimped using the am-3739 crimp tool.

This item can only be purchased in multiples of 25

You asked, we listened! These 3" diameter HD (heavy-duty) solid-core Compliant Wheels are intended for manipulating objects where you need a little 'give' in your intake system. These wheels deform out of the way to allow rigid objects to be manipulated easily. This makes for high-performance intakes and internal conveyors. These wheels do not require the use of expensive hubs to be driven, thanks to their integrated high strength polycarbonate hubs - which are made from the same mold that creates our Hex Molded Spacers.

Different durometer ratings give each wheel unique characteristics. Green compliant wheels (35A durometer) are the softest and most compliant around objects, while maroon (45A) blue (50A) and black (60A) wheels are increasingly firm.

Specifications

• Bore: 0.375 in. Hex, 0.5 in. Hex, 5 mm Hex
• Color: Green, Black, Blue, Black
• Core Material: Polycarbonate
• Diameter: 3 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.12 lbs
• Overall Width: 1 in.

Documents

Layout Print(s)

am-3946 3IN 375Hex Compliant Wheel REV3.PDF

am-3945 3IN 500Hex Compliant Wheel REV3.PDF

am-4537 3in 5mm Hex Molded Compliant Wheel.PDF

CAD File(s)

am-3946 3IN 375Hex Compliant Wheel REV 3.STEP

am-3945 3IN 500Hex Compliant Wheel REV 3.STEP

am-4537 3in 5mm Hex Molded Compliant Wheel.STEP

Snap action breakers are used commonly in mobile robot applications such as FIRST Robotics Competition power distribution boards. We offer several amperage versions.

Specifications

• Manufacturer: Snap Action
• Style: MINI, Auto-resetting
• Voltage: Up to 50V DC

Tip-to-tip length is approximately 12.6 inches. Want it longer or shorter? We offer this cable in custom lengths! Both end connectors are crimped with a 6-ton pneumatic crimping tool. One end has connections to attach to the battery and the other has an SB50 Anderson Connector. This cable is resistant to oil, most acids, grease, and even abrasion! That's a TOUGH cable.

Which do you prefer a stiff cable or a flexible cable? No matter your choice we have the best option in either camp. PVC insulated cables create a stiff wire route maintaining shape for repeatable connections. EPDM jacketed cables cand bend and twist to accommodate tight spaces and small places.

Specifications

• Connector : SB50, 1/4 in. Ring Terminal
• Gauge: 6
• Insulation: PVC or EPDM
• Operating Temperature: 257°F to -59°F
• Stranding: 263 inside EPDM Jacketed Wire
• Voltage: 60V Max
• Wire Type: Stranded
