3.5" OD x 3" ID x .25" X-Contact Bearing

Our improved and  stronger 12-volt DC motor with 100 rpm and 708 oz-in. of torque. The motor features a built-in, high-resolution Hall effect encoder for precise motor control and comes with an encoder cable.

A 61:1 gearbox comes standard.

Output Counts per Revolution of Output Shaft (cpr) 1,464 pulses

This motor is FTC Competition Legal

Specifications,

• 14AWG Parallel cable, silicone insulation
• 45A Anderson type single pole connector,Red & Black.
• XT30 Female type connector,Brass gold plated,PA
• 12cm length
• RoHS Compliant

The D-Shaft Collar is 6mm ID and 12mm OD. The inside diameter will fit any of the D-Shaft axels.

Specifcations:

• Material: 6061-T6 Aluminum

• Step File

Spare sets screws for Studica Robotics Hubs and Collars

10 Pack CONE HEX SOCKET SET SCREW DIN 914 M3 Thread

• 3 mm Long
• 1.5 mm Hex Socket
• 2 mm Socket Depth

The Intake Kit can be used to create intake systems and is ideal for the FIRST Technical Challenge (FTC) and World Robotics Olympiad (WRO). Used with the Silicone Rubber Tubing #76410

Specifications:

• Main piece
  • hex width: 20.78mm*10.0mm thick
  • 6*M6 tapped holes
  • 1*M4 tappped hole for M4 set screw
  • 6.0mm Diameter D Hole
  • Material AL6061-T6
  • Φ7.5mm*14.0mm
• Pins
  • 6PCS in a pack
  • M6*4.0mm thread
  • Material SS303
• Step file

Used with the Intake Kit to create various intake system with various lengths.

• ID: 6mm
• OD: 10mm
• 1000mm long
• Wall Thickness: 2mm
• Flexible
• Bend Radius: ~30mm
• Silicone
• Durometer: 70A
• Black
• Step File

The 25 Series Plate Sprockets: They roll! They turn! They spin! Everything you could possibly want from a plate sprocket.

These Aluminum sprockets work perfectly with hex shaft and mesh with #25 roller chain.

8 different offerings of our 25 Series Plate Sprockets. These are perfect for meshing with roller chain and finally getting that-thing-that-you-need-to-spin moving!

These aluminum sprockets work perfectly with any of our 6 hole hubs and mesh with #25 roller chain.  They also work with other build systems that use a 2 in. bolt circle for mounting. The larger versions also have a mounting pattern compatible with 2x1 box tube usefull for making arms.

Illuminate your robot with our 12V Individually Addressable LEDs. Chain them together to create cool lighting effects all over the robot! See user guide linked here and embedded below.

Specifications:

• Beam Angle: 120º
• IP Rating: IP30
• Input Voltage: 12VDC
• LED Quantity: 60 per meter
• Length: 16.4 feet
• Life Expectancy: 50, 000 hours
• Power: 21.6 W/M
• Width: 10mm

The 6mm round ID Flanged Bearing fits any of the channel and flat brackets with the common hole pattern having a center hole of 14mm. The inside diameter will fit any of the D-Shaft axels.

• Quantity: 12
• Material: AISI440C stainless steel
• Sealed Type: ZZ metal shields
• Precision: ABEC-3
• Clearance: C0
• Lubrication:Kyodo SRL Grease
• ID (inner diameter)/Bore:6 mm
• OD (outer diameter): 14 mm
• OD of Flanged Size: 15 mm
• Width: 5 mm
• Thickness of Flange: 1 mm
• Step File
