Thrifty Bearing Megaplate - QTY 2

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

Specifications

• Drive: 5/32 in. Hex
• Finish: Zinc
• Head: Socket Cap
• Length: 1.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.02 lbs

This item can only be purchased in multiples of 10

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 10-32
• Length: 1-3/4"
• Head: Socket Head Cap Screw

These aluminum box extrusions are robust and lightweight solutions for custom robot frames, superstructures and mechanism construction. Made to all of your favorite English sizes, the classic 2x1 thin wall tubing is now joined by its thicker-walled counterpart. We have also introduced two thicknesses of 1x1 sizes that teams know and love to build their medium-sized mechanisms.

For smaller mechanisms, we recommend using our 5/8 square box tube that is also compatible with the S3 line of brackets and gussets.



Available Sizes:

• 2 x 1 x 1/16 in. (0.063 in.) 6061-T6 alloy
• 2 x 1 x 1/8 in. (0.125 in.) 6061-T6 alloy
• 1 x 1 x 1/16 in. (0.063 in.)6061-T6 alloy
• 1 x 1 x 1/8 in. (0.125 in.)6061-T6 alloy
• 5/8 x 5/8 x 1/16 in. (0.063 in.) 6061-T6 alloy
• All lengths are (+/- 1in)

Be sure to all check out our Gussets as they work wonderfully with all of these wonderful extrusions.

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

Each hub now has a "flower" pattern that fits and keys into our 42T 5 mm HTD Pulley, which means you are no longer constrained to our legacy 500EX Hex Hub for compatibility with this pulley. Every hub still maintains a closed-profile hole for maximum strength. Every shaft hub has been designed with bearing bosses on both sides that have been sized appropriately for the mating bearings that would pair with the bore through the hub, which means you can run each hub right against a bearing with no need for extra spacers. All of these hubs are also made from 7075-T6 aluminum, which is much stronger than the previously used 6061-T6, 6005, and 6105 alloys from our older designs. Where possible, the shoulder on shaft hubs was reduced to 7/8" in diameter for an easier fit with our molded plastic wheels, while still maintaining a precise 1.125" diameter boss for locating in wheels, sprockets, gears, and more.

The holes are evenly spaced on a 1.875 in. circle and 0.201 inches in diameter. That's a perfect size for #10 bolts!

Learn how to attach these hubs to AndyMark wheels by watching this video!

Expand your robot's capabilities and build easier with the Thrifty Grid Pattern Aluminum Extrusion.

Tubes are 47" long. Holes are 5mm (.197) in diameter with 1/2" grid spacing. Material is 6061 T-6 aluminum.

Style: .125" Wall Thickness

This is the 8 in. SmoothGrip wheel. In 2010, the Gray 80A Durometer version was provided in the FRC Kit of Parts under the name "FIRST Wheel". No bearings are included.

New for 2021, you can now select a Blue 50A Durometer for maximum traction, or a Black 60A Durometer option.

Usage With Axle and Hub:

• If you wish to drive this wheel with an axle and hub, you can pick your hub by fitting any of the AndyMark hubs to this wheel. Hubs are not included with this wheel. If this is your choice, then no bearing is needed. To install a hub onto this wheel, use #10-24x3/4 thread forming screws.

Usage With Sprockets and Bearings:

• If you wish to drive this wheel with a sprocket, then the sprocket needs to be attached to the side of the wheel with #10-24x3/4 thread forming screws. You will also need to press ball bearings into the wheel so that it may spin on a shaft or bolt. The ball bearings must have a 1.125 in. od. For a 1/2 in. shafts, use am-0181. For a 3/8 in. shafts use am-0209.

Specifications

• Bolt Pattern: six holes (0.17 in. diameter) on a 1.875 in. diameter bolt circle.
• Bore: 0.95 in. diameter through hole, with two 1.125 in. diameter bearing pockets
• CoF: 1.0 static (on tight pile carpet)
• Diameter: 8 in.
• Durometer: 50A, 60A, 80A
• Material: black polycarbonate, urethane rubber
• Weight: 0.62 lbs

Documents

CAD File(s)

am-0420 8in Rubber Treaded Wheel.STEP

Layout Print(s)

am-0420 8in Smooth Grip Wheel.PDF

A familiar button layout brings console-style control to your robot controls. No matter what the FIRST FRC game, you’ll have control for every race, battle or tournament. Button customization, multiple controller configurations, printable gaming profiles—it’s your game, your way. All the controls are just where you expect them to be thanks to the standard button layout of this gamepad.

Specifications:

XINPUT MODE:

• A, B, X, Y buttons
• LB, RB buttons
• Left and right analog triggers
• Start and Back buttons
• Two clickable analog mini-joysticks
• 8-way D-pad
• Home button
• Sports mode

DIRECTINPUT MODE:

• 10 programmable buttons*
• Programmable left and right triggers*
• Two programmable analog mini-joysticks*
• 8-way programmable D-pad*
• Sports mode

Tip-to-tip length is approximately 12.6 inches. Want it longer or shorter? We offer this cable in custom lengths! Both end connectors are crimped with a 6-ton pneumatic crimping tool. One end has connections to attach to the battery and the other has an SB50 Anderson Connector. This cable is resistant to oil, most acids, grease, and even abrasion! That's a TOUGH cable.

Which do you prefer a stiff cable or a flexible cable? No matter your choice we have the best option in either camp. PVC insulated cables create a stiff wire route maintaining shape for repeatable connections. EPDM jacketed cables cand bend and twist to accommodate tight spaces and small places.

Specifications

• Connector : SB50, 1/4 in. Ring Terminal
• Gauge: 6
• Insulation: PVC or EPDM
• Operating Temperature: 257°F to -59°F
• Stranding: 263 inside EPDM Jacketed Wire
• Voltage: 60V Max
• Wire Type: Stranded
