Hex Molded Spacers, 1/2 Hex, 0.5 inch length

Must be ordered in mulitples of 25

This item can only be purchased in multiples of 25

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: #10-32
• Thickness: 0.249"
• Thread: Fine
• Thread Size: 32
• Type: Nylon Insert Lock Nut
• Wrench Size: 3/8"

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 1/4-20
• Width across hex: 7/16"

This item can only be purchased in multiples of 25

The Bumper Wood Corner Bracket is designed to connect two plywood planks together to form a strong 90 degree bumper corner.

Specifications

• Material: 5052 Aluminum

Documents

Layout Print(s)

am-3233 AM14U3 Bumper Outside Corner Bracket.PDF

CAD File(s)

am-3233 AM14U3 Bumper Corner Bracket.STEP

Tee nuts are used to put steel threads into wood. Drill a hole sized to fit the barrel, then hammer in the locking prongs until the top of the tee nut is flush with the surface. This creates a strong fastening method between wooden components and other components.

This new custom designed collar clamp has been designed specifically with FIRST Robotics Competition teams in mind. This product is Out of Stock until Mid March

Whether you are building an elite custom drivetrain or a championship manipulator, you need your components to stay where they're supposed to. These lightweight spacers come in 3/8", 1/2", and 5 mm hex bores to accommodate the most common shaft types They can also be used on round shafts and bolts (5mm is great for #10 hardware!). If you need to space a lot grab some 1" spacers. If you need ultimate precision pick up some 0.063" spacers. Not sure which spacers you need? Keep a handful of all six sizes in your shop and never go hungry for spacers again!

These spacers are molded in black polycarbonate, a tough, crack resistant material that FIRST teams are familiar with. These spacers should resist stress cracking. If polycarbonate isn't rugged enough for your high load application or you need custom length spacers, check out our Aluminum Hex Spacer Extrusion.

Specifications

• Inside Diameter: 0.375 in. Hex, 0.50 in. Hex, 5 mm Hex
• Length: 0.063 in., 0.125 in., 0.188 in., 0.250 in., 0.375 in., 0.50 in., 1.00 in.
• Material: Polycarbonate
• Outside Diameter: 0.787 in. Round
• Weight: Up to 0.014 lbs

This is a Heavy Duty Hex Bearing which outperforms our previous 1/2" Hex Bearings as it has a Heavy Duty Inner Race. This FR8ZZ-HexHD bearing, 1/2" hex bore, flanged, heavy duty inner race, shielded ball bearing, has an inner race that is thicker and stronger than our recent offering of a similar bearing (am-0279). This bearing has more material between the corners of the hex bore and the edge of the race making it stronger and much less likely to crack under high load.

This bearing is guaranteed to have a stronger, thicker race. 100% of these bearings have been quality checked for a smooth fit over 1/2" hex stock here at AndyMark. Many of our long-time customers will recognize this bearing, as it is the same version we sold back in 2008-2011, and we did not have any failures. Now, it is renamed and quality checked for your high load needs - including drive chassis with cantilevered wheels.

Specifications:

• Inside diameter: 0.500-0.502 inch hex bore
• Outside diameter: 1.125 inch
• Flange thickness: 0.062 inch
• Overall thickness: 0.312 inch
• Weight: 0.05 pound

1/2 inch external retaining ring, used in the RAW Box.

Specifications:

• Material: Steel
• For Shaft Diameter: 1/2"
• Thickness: 0.031"
• Type: External Retaining Ring
• Free Inside Diameter: 0.456"
• Plier Hole Diameter: 0.40"
• Weight: 0.002 pounds

Looking or a flat profile wheel with plenty of grip? Look no further than our six inch SmoothGrip wheels! Many are familiar with our flagship HiGrip wheels which feature an aggressive tread pattern great for biting hard into the ground. SmoothGrip wheels provide a strong level of traction with a longer life-span thanks to their smooth profile. They make great drive wheels on almost any surface as well as great flywheels to propel game pieces at high speed without damage. SmoothGrip wheels feature your favorite 1.125 in. bearing bore and 1.875 in. bolt circle, allowing you to mount a hub or bearing of your choice for live or dead axle setups.

Please note, due to the way these wheels are molded the outer profile may be tapered slightly to one side, this does not significantly affect performance as a drive wheel in most applications.

Specifications

• Body Material: Polycarbonate
• Bolt Pattern: 6 holes (0.157in.) on a 1.875 in. bolt circle
• Bore: 1.125 in. Pocket, 0.96 in. Thru
• Diameter: 6 in.
• Durometer: 80A, 60A, 50A
• Load Capacity: 100 lb
• Tread Material: TPU
• Weight: 0.58 Lbs

Documents

CAD File(s)

am-0144a SmoothGrip Wheel.STEP

Layout Print(s)

am-0144a SmoothGrip Wheel.PDF
