Thrifty Clamping Bearing Block

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: 10-32
• Length: 3/4"
• Head: Socket Head Cap Screw

Specifications

• Drive: 5/32 in. Hex
• Finish: Zinc
• Head: Socket Cap
• Length: 1.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.02 lbs

This item can only be purchased in multiples of 10

Specifications:

• Material: Steel
• Coating: Zinc plated
• Thread: 10-32
• Length: 1-3/4"
• Head: Socket Head Cap Screw

You asked, we listened! These 3" diameter HD (heavy-duty) solid-core Compliant Wheels are intended for manipulating objects where you need a little 'give' in your intake system. These wheels deform out of the way to allow rigid objects to be manipulated easily. This makes for high-performance intakes and internal conveyors. These wheels do not require the use of expensive hubs to be driven, thanks to their integrated high strength polycarbonate hubs - which are made from the same mold that creates our Hex Molded Spacers.

Different durometer ratings give each wheel unique characteristics. Green compliant wheels (35A durometer) are the softest and most compliant around objects, while maroon (45A) blue (50A) and black (60A) wheels are increasingly firm.

Specifications

• Bore: 0.375 in. Hex, 0.5 in. Hex, 5 mm Hex
• Color: Green, Black, Blue, Black
• Core Material: Polycarbonate
• Diameter: 3 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.12 lbs
• Overall Width: 1 in.

Documents

Layout Print(s)

am-3946 3IN 375Hex Compliant Wheel REV3.PDF

am-3945 3IN 500Hex Compliant Wheel REV3.PDF

am-4537 3in 5mm Hex Molded Compliant Wheel.PDF

CAD File(s)

am-3946 3IN 375Hex Compliant Wheel REV 3.STEP

am-3945 3IN 500Hex Compliant Wheel REV 3.STEP

am-4537 3in 5mm Hex Molded Compliant Wheel.STEP

This is a Heavy Duty Hex Bearing which outperforms our previous 1/2" Hex Bearings as it has a Heavy Duty Inner Race. This FR8ZZ-HexHD bearing, 1/2" hex bore, flanged, heavy duty inner race, shielded ball bearing, has an inner race that is thicker and stronger than our recent offering of a similar bearing (am-0279). This bearing has more material between the corners of the hex bore and the edge of the race making it stronger and much less likely to crack under high load.

This bearing is guaranteed to have a stronger, thicker race. 100% of these bearings have been quality checked for a smooth fit over 1/2" hex stock here at AndyMark. Many of our long-time customers will recognize this bearing, as it is the same version we sold back in 2008-2011, and we did not have any failures. Now, it is renamed and quality checked for your high load needs - including drive chassis with cantilevered wheels.

Specifications:

• Inside diameter: 0.500-0.502 inch hex bore
• Outside diameter: 1.125 inch
• Flange thickness: 0.062 inch
• Overall thickness: 0.312 inch
• Weight: 0.05 pound

Tired of hex clamp collars that cost an arm and a leg? Tired of stripping out the set screw on your clamp collar? Need to add a collar in an assembly and don't want to remove everything from your hex shaft?

Me too! I've ran into all of the above scenarios multiple times building multiple robots. These collars are the holy grail -

• split so they can easily be added or removed
• lightweight 6061 aluminum
• .5 oz (.031 lbs) for one hex collar
• uses two 8-32 socket head cap screws that require a 9/64" allen wrench
• $4.00 per collar, sold in 5 packs
• anodized black for awesomeness

General Dimensions:

• When clamped on 1/2 inch hex shaft - approx 1.2 inch outer diameter
• 0.40 inches wide
• STEP file CAD Model Available

This new custom designed collar clamp has been designed specifically with FIRST Robotics Competition teams in mind. This product is Out of Stock until Mid March

These aluminum box extrusions are robust and lightweight solutions for custom robot frames, superstructures and mechanism construction. Made to all of your favorite English sizes, the classic 2x1 thin wall tubing is now joined by its thicker-walled counterpart. We have also introduced two thicknesses of 1x1 sizes that teams know and love to build their medium-sized mechanisms.

For smaller mechanisms, we recommend using our 5/8 square box tube that is also compatible with the S3 line of brackets and gussets.



Available Sizes:

• 2 x 1 x 1/16 in. (0.063 in.) 6061-T6 alloy
• 2 x 1 x 1/8 in. (0.125 in.) 6061-T6 alloy
• 1 x 1 x 1/16 in. (0.063 in.)6061-T6 alloy
• 1 x 1 x 1/8 in. (0.125 in.)6061-T6 alloy
• 5/8 x 5/8 x 1/16 in. (0.063 in.) 6061-T6 alloy
• All lengths are (+/- 1in)

Be sure to all check out our Gussets as they work wonderfully with all of these wonderful extrusions.

This 8 pack of 2.5mm thick T gussets can be used to assemble frames or other mechanisms commonly used in competitive robotics.

• 3.50 in. x 3.25 in. with 1 inch wide ends
• .163" holes spaced 1/2 an inch apart, perfect for 5/32 rivets
• 2.5mm (0.098 in.) thick, made from 6061-T6 aluminum
• .055 lbs per L gusset
• Sold in 8 packs

CAD model available

This 8 pack of 2.5mm thick L gussets can be used to assemble frames or other mechanisms commonly used in competitive robotics.

• 2.75 in. x 2.75 in. with 1 inch wide ends
• .163" holes spaced 1/2 an inch apart, perfect for 5/32 rivets
• 2.5mm (0.098 in.) thick, made from 6061-T6 aluminum
• .04 lbs per L gusset
• Sold in 8 packs

CAD model available
