M3 x 10mm Low Profile Screw with Kep Nut (6 pack)

The Studica Slide Rail is made of light weight aluminum, is 24mm wide, and is perfect for building a multi-stage slide system. Closed length is 384m, with a 240mm stroke, creating a 530mm extended length.

IN STOCK

• Width: 24mm
• Height: 7.2mm
• Length: 384mm
• Stroke: 240mm
• Extendended length: 530mm
• Material: 6061 Aluminum
• Step file

The Motor Mount Plate is used with the Maverick 12V DC Gear Motor  (Part# 75001) to attach it inside the anyone of the U Channels 76010 to 76018. This is an example of a chassis with 4 motors mounted inside the U-Channel using a Motor Mounting Plate.

• Step File

GT2-6mm Smooth Idler Pulley, H Type, w/3mm Inner Bore Bearing

·      450mm Length

·      3 position

·      TJC8 MH-FC on one end

·      TJC8 FH-MC on the other end

·      Twisted cable

·      Colors: White, Red, Black (red in middle)

·      24AWG Guage

The 100mm (4 inch)  Double Plastic Omni Wheel provides rotational and sideways 360° maneuverability.  Great for omni directional movement and rotation, easy direction control and tracking, and for fast turning,

Specifications:

• Diameter:   100mm (4")
• Axial width:  16mm
• Hub:    6mm (included)
• Number of plate:  2
• Number of roller: 18
• Body material:    Nylon
• Roller material:   Rubber
• Roller diameter:  19mm
• Net weight:          275g
• Load capacity:    20kg
• Step File

The Powerpole Extension Cable is 50cm long and 14AWG wire gauge to handle heavier loads.

Used with Studica Omni and Mecanum wheels for a strong axel hold.

Specifications:

• Material: 6061-T6 Aluminum
• Color: Blue
• Step File

Used to change motor to axle motion 90 degrees. This can be used in between the U-channel.

Specifications:

• Material: Steel
• Number of teeth: 30
• Set of 2 for 1-1 drives
• Step File

This linear motion closed type slide unit has an 8 mm inside diameter. The slide unit, designed to carry a component, has a housing with a flat mounting face and four tapped bolt holes, and circle clips at each end to retain the ball bushing. Ball in the cage loop to run a smooth ball guide surface to ensure even if high-speed operation, low noise. Used with WSR Linear Motion Shaft - 8mm(D) x 496mm(L)

Features:

• Closed type bushing block and ball bushing insert for use in linear motion applications
• Four-bolt aluminum alloy bushing block for a lightweight ready-to-mount installation
• Synthetic resin retainer plate for accurate ball guidance and low noise
• Four rows of recirculating balls inside the ball bushing for smooth running
• Integral lip seals to retain lubricant and protect against contamination

This linear motion shaft of 8 mm in diameter and 496 mm in length is chrome plated and case hardened, and is suitable for use with slide units in linear motion applications. The high-carbon steel shaft is chrome plated for corrosion resistance, case hardened for wear resistance, and precision ground for consistent ball bushing radial clearance. Used with WSR Linear Motion Slide Unit 8mm(ID) -2 pack

Features:

• Round steel shaft for use with slide units in linear motion applications.
• Chrome plated for corrosion resistance
• Case hardened for wear resistance
• Precision ground for consistent ball bushing radial clearance
