On/Off Power Switch - 20A125VAC

TETRIX MAX Bevel Gear & Acetal Bearings includes two heavy-duty aluminum gears along with two acetal bearings that allow for the transfer of the direction of motion at 90 degrees.

• Quantity: pkg of 2 gears and 2 bearings
• Number of Teeth: 30
• Diameter: Bevel Gear diameter 59.87 mm
• Thickness: 10.85 mm
• Material: 7005 Aluminum gears, Acetal bearings

• Used with M3 screws

The 6mm diameter D -Shaft is made of stainless steel and is used throughout our building system as drive components. The D-Shaft profile is used with pulleys, gears and hubs when tightening the set screws and creating a non-slip connection.

Specifcation:

• Stainless Steel
• 432mm length
• 6mm OD
• 5.5mm to flat
• Step File

Specifications:

• 7 color pcs
• 1.5, 2, 2.5, 3, 4, 5, 6
• Non-slip handle
• ball-end and straight-end
• S2 Hardness
• Non-corrosive
• Weight: 0.118kg

ODΦ20.0mm*ID14.0mm
*3.0mm thick
8*Φ3.50mm holes
10pcs per pack
Delrin
Blue

The Intake Kit can be used to create intake systems and is ideal for the FIRST Technical Challenge (FTC) and World Robotics Olympiad (WRO). Used with the Silicone Rubber Tubing #76410

Specifications:

• Main piece
  • hex width: 20.78mm*10.0mm thick
  • 6*M6 tapped holes
  • 1*M4 tappped hole for M4 set screw
  • 6.0mm Diameter D Hole
  • Material AL6061-T6
  • Φ7.5mm*14.0mm
• Pins
  • 6PCS in a pack
  • M6*4.0mm thread
  • Material SS303
• Step file
