1/4 in. ID 5/8 in. OD Shielded Flanged Bearing (FR4ZZ)

Specifications

• Flange: Unflanged
• Inside Diameter: 0.375 in.
• Outside Diameter: 0.875 in.
• Overall Thickness: 0.281 in.
• Seal Type: Shielded
• Style: Radial
• Weight: 0.03 lbs
• Width: 0.281 in.

Documents

Layout Print(s)

am-0516 0375IN ID bearing, shielded (R6ZZ) REV2.PDF

CAD File(s)

am-0516 0.375'' id bearing, shielded (R6ZZ).STEP

This is a 1/4 in. round bore bearing that is unflanged. The Shielded Ball Bearing is a great way to make things spin fast!

3/8" id shielded, flanged ball bearing

Specifications:

• Inside Diameter: 0.375 inch
• Outside Diameter: 0.875 inch
• Flange Thickness: 0.062 inch
• Overall Thickness: 0.280 inch
• Weight: 0.026 pounds
• Material: Steel

0.75" x 0.85", nylon, 0.75" od, 0.38" id, 0.85" thick, white

Specifications:

• Material: White Nylon Plastic
• Inside Diameter: 0.38 inch
• Outside Diameter: 0.75 inch
• Thickness: 0.85 inch
• Weight: 0.0014 pounds

Specifications

• Bore: 0.252 in. [6.4 mm] Round
• Inside Diameter: 0.252 in. [6.4 mm]
• Length: 2.750 in. [69.9 mm] (2-3/4)
• Material: Nylon
• Outside Diameter: 0.625 in.

#35 Half Link. Also known as #35 Offset Link.

Specifications:

• Material: Steel
• Style: Roller Chain with interted pin
• Type: Half Link
• Size: #35
• Pitch: 0.375 inch
• Weight: 0.01 lbs

#35 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #35
• Pitch: 0.375 inch
• Weight: 0.01 lbs

#25 Half Link. Also known as #25 Offset Link.

Specifications:

• Material: Steel
• Style: Roller Chain with interted pin
• Type: Half Link
• Size: #25
• Pitch: 0.25 inch
• Weight: 0.01 lbs

#25 Connecting Link (Master Link)

Specifications:

• Material: Steel
• Style: Roller Chain - Spring Clip
• Type: Connecting Link
• Size: #25
• Pitch: 0.250 inch
• Weight: 0.01 lbs

Tip-to-tip length is approximately 12.6 inches.
