Product Overview

These blind steel rivets are a perfect, strong choice for creating frames when using our 1in. Gussets paired with up to .125" wall aluminum tubing. These steel rivets won't let you down when you need them most!

Specifications

• Diameter: 3/16 in.
• Drill Size For Hole: #11
• Finish: Zinc
• Grip Range: 0.126-0.25 in.
• Head: Buttonhead
• Hole Size: 0.192-0.196 in.
• Length: 0.45 in.
• Mandrel Material: Steel
• Material: Steel
• Rivet Style: Blind
• Weight: 0.0094

This item can only be purchased in multiples of 25

#10-32 x 0.5 in. long Socket Head Cap Screw

Specifications

• Finish: Zinc
• Head: Socket Cap
• Length: 0.5 in.
• Material: Steel
• Thread: 10-32
• Weight: 0.1 lbs

This item can only be purchased in multiples of 25

Specifications:

• Material: Steel
• Coating: Zinc Plated
• Thread: #10-32
• Thickness: 0.249"
• Thread: Fine
• Thread Size: 32
• Type: Nylon Insert Lock Nut
• Wrench Size: 3/8"

We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.

On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.

Specifications

• Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
• Material: 6061-T6 Aluminum
• Thickness: 0.125 in

Documents

Layout Print(s)

am-3860 90 Gusset REV2.PDF

am-4158 1IN Tee Gusset.PDF

am-4159 1IN Quad Gusset.PDF

am-4160 1IN 30deg Gusset.PDF

am-4161 1in 45deg Gusset.PDF

am-4162 1in 60deg Gusset.PDF

am-4163 1in 120deg Gusset.PDF

am-4164 1in 135deg Gusset.PDF

am-4165 1in 150deg Gusset.PDF

am-4166 1IN Sport Double Bearing Mount.PDF

am-4167 1IN 57Sport Side Mount Gusset.PDF

am-4168 1IN Bearing Side Mount Gusset.PDF

CAD File(s)

am-3860 90 Gusset REV2.STEP

am-4158 1IN Tee Gusset.STEP

am-4159 1IN Quad Gusset.STEP

am-4160 1IN 30deg Gusset.STEP

am-4161 1in 45deg Gusset.STEP

am-4162 1in 60deg Gusset.STEP

am-4163 1in 120deg Gusset.STEP

am-4164 1in 135deg Gusset.STEP

am-4165 1in 150deg Gusset.STEP

am-4166 1IN Sport Double Bearing Mount.STEP

am-4167 1IN 57Sport Side Mount Gusset.STEP

am-4168 1IN Bearing Side Mount Gusset.STEP

This is the "500EX Hex Hub" the bore is a 1/2" Hex Hole. It is a slightly different version of the 500 Hex Hub. It is manufactured differently, as it is extruded. Also, there is a 1.124" diameter boss on each side of the hub flange, providing a location for 1.125" bore flat sprockets. Are you having a hard time keeping your sprocket concentric with your hub? This hub is the trick.

This is the hub featured in the 2014 and 2015 Kit of Parts Drive Chassis and fits all AndyMark wheels.

Specifications:

• Material: 6063 Aluminum
• Bore: 1/2" Hex
• Bolt Pattern: 0.204" diameter holes, evenly spaced on a 1.875" diameter bolt circle
• Outside diameter: 2.25"
• Weight: .088

The Sensor Extension Cable extends the length available for creating connections from the TETRIX PRIZM Robotics Controller to a sensor. Each cable is 30 cm long.

This 20 Amp fuse is used in FIRST Tech Challenge batteries and the FIRST Robotics Competition Power Distribution Panel (am-2856).

Specifications:

• Color: Yellow
• Amps: 20
• Max Voltage: 32
• Style: MINI®
• Specification: SAE J2077
• Type: Blade Fuse

This is a Heavy Duty Hex Bearing which outperforms our previous 1/2" Hex Bearings as it has a Heavy Duty Inner Race. This FR8ZZ-HexHD bearing, 1/2" hex bore, flanged, heavy duty inner race, shielded ball bearing, has an inner race that is thicker and stronger than our recent offering of a similar bearing (am-0279). This bearing has more material between the corners of the hex bore and the edge of the race making it stronger and much less likely to crack under high load.

This bearing is guaranteed to have a stronger, thicker race. 100% of these bearings have been quality checked for a smooth fit over 1/2" hex stock here at AndyMark. Many of our long-time customers will recognize this bearing, as it is the same version we sold back in 2008-2011, and we did not have any failures. Now, it is renamed and quality checked for your high load needs - including drive chassis with cantilevered wheels.

Specifications:

• Inside diameter: 0.500-0.502 inch hex bore
• Outside diameter: 1.125 inch
• Flange thickness: 0.062 inch
• Overall thickness: 0.312 inch
• Weight: 0.05 pound

Add vision to your PRIZM^®-controlled robot! This adapter enables easy attachment of a Pixy2 camera to your TETRIX^® robot as it includes a port for connection to a PRIZM controller with the provided sensor extension cable.

Vision sensors like the Pixy2 camera are useful for all kinds of robotics applications and tasks. Making navigation decisions, tracking and sorting objects, identifying patterns, avoiding obstacles, and detecting motion are just a few examples of how vision can enhance a robot. The Pixy2 camera can recognize objects based on color, has an advanced line-tracking algorithm that even allows for navigating intersections, and can be used as a color sensor to determine the RGB value of an object. To accomplish these and other tasks, Pixy2 provides lots of data to the PRIZM controller.

It’s easy to incorporate the Pixy2 sensor into your coding lessons using the free, downloadable Pixy2 Camera TETRIX Extension Activity, which follows the format of the PRIZM Programming Guide. Extend learning with the free downloadable Robotics Engineering Challenge. Both are available in the Resources section of this page.

The Pixy2 camera, PRIZM controller, and TETRIX set are not included.

These adapters are intended to be a high strength solution to adapt the Falcon Spline to any product that has a 1/2 in hex bore. This product includes the correct size washers to retain items along the hex shaft, as well as a thread-patch 8-32 screw to be used in conjunction with spacers included with the Falcon 500 motor to retain motion hardware.
