SPARK MAX CAN Cable

The Sushi Roller Intake Wheels are an excellent choice for robot intakes, internal conveyors, feeder mechanisms, or anywhere you need a durable, compact and grippy roller. These rollers are made with a robust polycarbonate hex bore hub, so no external hub is necessary - just slide them onto a hex shaft, constrain them axially and you are good to go. Available in a range of durometers for a wide variety of applications, these cute little rollers are great for getting a grip on things!

Specifications

• Bore: 0.5 in. Hex, 5 mm Hex, 0.375 in. Hex
• Core Material: Polycarbonate
• Diameter: 1 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.022 lbs
• Width: 1 in.

The Sushi Roller Intake Wheels are an excellent choice for robot intakes, internal conveyors, feeder mechanisms, or anywhere you need a durable, compact and grippy roller. These rollers are made with a robust polycarbonate hex bore hub, so no external hub is necessary - just slide them onto a hex shaft, constrain them axially and you are good to go. Available in a range of durometers for a wide variety of applications, these cute little rollers are great for getting a grip on things!

Specifications

• Bore: 0.5 in. Hex, 5 mm Hex, 0.375 in. Hex
• Core Material: Polycarbonate
• Diameter: 1 in.
• Durometer: 35A (Green), 40A (Orange), 50A (Blue), 60A (Black)
• Tread Material: TPU
• Weight: 0.022 lbs
• Width: 1 in.

This is a Heavy Duty Hex Bearing which outperforms our previous 1/2" Hex Bearings as it has a Heavy Duty Inner Race. This FR8ZZ-HexHD bearing, 1/2" hex bore, flanged, heavy duty inner race, shielded ball bearing, has an inner race that is thicker and stronger than our recent offering of a similar bearing (am-0279). This bearing has more material between the corners of the hex bore and the edge of the race making it stronger and much less likely to crack under high load.

This bearing is guaranteed to have a stronger, thicker race. 100% of these bearings have been quality checked for a smooth fit over 1/2" hex stock here at AndyMark. Many of our long-time customers will recognize this bearing, as it is the same version we sold back in 2008-2011, and we did not have any failures. Now, it is renamed and quality checked for your high load needs - including drive chassis with cantilevered wheels.

Specifications:

• Inside diameter: 0.500-0.502 inch hex bore
• Outside diameter: 1.125 inch
• Flange thickness: 0.062 inch
• Overall thickness: 0.312 inch
• Weight: 0.05 pound

The inside black portion of this wheel is made from molded polycarbonate plastic. The outer tread is TPU (Thermoplastic PolyUrethane). This robust but lightweight wheel provides good traction on carpet and soft tiles. Stealth wheels are the perfect drive wheel for smaller (<50 lb.) robots, or for intakes and other auxiliary robot mechanisms. These wheels are available in a variety of bores and durometers. 4 in. Stealth Wheels feature a 6 bolt pattern on a 1.875 in. bolt circle for mounting sprockets, hubs, and gears. Nub Bore Stealth Wheels feature a 4 bolt pattern on a 16 mm bolt circle found in most FIRST Tech Challenge building systems. The lower the durometer the softer the wheel is, this makes it wear away faster, but also makes it more grippy.

Product Usage:
Many thread locking materials are not compatible with polycarbonate and can eat away at the plastic. Be sure to check which adhesives are okay to use with this product.

Specifications

• Bore: 1/2 in. Hex, 3/8 in. Hex, Nub Bore, 5 mm Hex
• Diameter: 2 in., 4 in.
• Durometer: 35A (Green), ⠀40A (Orange), ⠀50A (Blue), ⠀60A (Black), ⠀80A (Gray)
• Hole Pattern: Qty 4 3.5 mm Holes on a 16 mm Circle for 8 mm bore wheels
• Material: TPU, Polycarbonate
• Weight: 0.23lb, 0.1lb
• Width: 1 in.

Documents

Layout Print(s)

am-3664 2in 5mm Hex Stealth Wheel REV4.PDF

am-3156 2IN 8mm Stealth Wheel REV3.PDF

am-3436 2in 375Hex Stealth Wheel REV3.PDF

am-3155 2in 500Hex Stealth Wheel REV3.PDF

am-3665 4in 5mm Hex Stealth Wheel REV3.PDF

am-2648 4IN 8mm Stealth Wheel REV5.PDF

am-3435 4in 375Hex Stealth Wheel REV3.PDF

am-2647 4in 500Hex Stealth Wheel REV3.PDF

CAD File(s)

am-3664 2in 5mm Hex Bore Stealth Wheel REV3.STEP

am-3156 2IN 8mm Stealth Wheel.STEP

am-3436 2IN 375Hex Stealth Wheel REV2.STEP

am-3155 2IN 500Hex Stealth Wheel REV2.STEP

am-3665 4IN 5mm Hex Stealth Wheel REV2.STEP

am-2647 4inWheel 500 Hex REV2.STEP

am-3435 4in Wheel Integrated Hub 375 HEX with Tread REV2.STEP

am-2648 4inWheel 8mm Hub REV2.STEP

This collar clamp is a one-piece shaft collar with a 1/2 in. bore, 0.984 in. OD, and 0.236 in. width. The thin line design reduces weight and allows for use in confined spaces. It has the clamp style benefits of not marring the shaft, easy removability, and indefinite adjustability while commonly being used for guiding, spacing, stopping, mounting, and component alignment.

Specifications:

• Material: 2024 Aluminum
• Bore: 0.500 in.
• Outside Diameter: 0.984 in.
• Thickness: 0.236 in.
• Weight: 0.017 Pounds
• Clamping Screws: M2 5x8 SHCS

The 6" Performance Wheel is a competition-proven design used by many top teams over the years. This wheel design incorporates a novel way of attaching tread, and also allows for sprockets to be mounted on both sides of the wheel. This wheel DOES NOT include tread material, which is available separately to tailor this wheel's performance to your application. Two 1.125" OD bearings, available separately, allow this wheel to ride smoothly on a dead (stationary) axle of your choosing.

For tread mounting instructions, click here!

Specifications:

• Material: 6061 aluminum, machined from billet
• Diameter: 5.60 inches, without tread (6.0 inches with tread, not included)
• Weight: 0.57 pound
• Uses 1" wide treads
• Bore: 0.95" with 1.1245" id x 0.250" deep on either side
• Load Capacity: 500 pounds*
• Tread Mounting Holes: 6 threaded thru holes for #10-32 screw on a 1.875" dia bolt circle

* Load Testing: we applied 700 pounds on the location of the opening for the treads, and had no rim deflection.

Usage:
With Sprocket:

One sprocket on one side: To drive this wheel with a sprocket, (or to drive another wheel with propulsion from this wheel) then the sprocket needs to be attached to the side of the wheel, outside of a 250 Sprocket Spacer. Use Hardware Kit 3, which includes the screws for this.

• Two sprockets, one on each side: One side of the wheel has no recess, so that side will only need a 250 Sprocket Spacer to space the sprocket out from the wheel. In order to put a sprocket on the other side, use a 550 Sprocket Spacer to get the sprocket out far enough so that the chain clears the edge of the wheel.

With Bearing:

• Press a ball bearing into this wheel for a free spinning wheel or for use with a sprocket.. The ball bearing must have a 1.125" od. For a 1/2" id, use am-0030. For a 3/8" id, use am-0573.

With Axle and Hub:

• This wheel can be driven by a an axle, if an AndyMark hub is attached to the wheel. Hubs are NOT included in the price of the wheel. If this is your choice, then no bearing is needed. To install a hub onto a 6" Performance Wheel, use Hardware Kit 3.

FOR SALE TO CANADIAN TEAMS ONLY

This is the game piece for the 2024 FIRST® Robotics Competition CRESCENDO℠ presented by Haas. It has a 14 in. OD and a 10 in. ID and is rather squishy / flexible.

There are 113 total Notes on a field, 6 of which are “High Notes” that have white Gaff Tape (not included) applied as specified in the Game Manual.

The breakdown is:

• 45 in Red Player Station
• 45 in Blue Player Station
• 3 for pre-load in Red Robots
• 3 for pre-load in Blue Robots
• 5 in Center Field
• 3 in Red Alliance Starting Zone
• 3 in Blue Alliance Starting Zone
• 6 High Notes for Human Players

For optimal shipping efficiency please know that Notes ship from the manufacturer in boxes of 24 (but can be ordered in any quantity).

Specifications

• Inside Diameter: 10 in.
• Material: Coated Foam
• Outside Diameter: 14 in.
• Thickness: 2 in.
• Weight: 8.3 Oz +/- 1 Oz

Expand your robot's capabilities and build easier with the Thrifty Grid Pattern Aluminum Extrusion.

Tubes are 47" long. Holes are 5mm (.197) in diameter with 1/2" grid spacing. Material is 6061 T-6 aluminum.

Style: .125" Wall Thickness

Specifications:

• Pitch: 5 mm
• Length:
• Width: 9 mm
• Number of Teeth: 48
• Weight: 0.05 Pounds

This is 22 AWG (gauge) bonded wire with Black/Red and White Jacketing. It lets you create your own length PWM cable.

Specifications

• Gauge: 22
• Length: 10 ft
• Wire Jacketing: black/red/white (bonded together)
