8mm to 1/2 in. Hex Shaft Adapter - Long
This adapter converts an 8 mm keyed shaft to 1/2 in. hex. The keyway is 2 mm wide. This allows you to adapt the output of a motor or gearbox like the CIM Motor (am-0255) to any of our hubs or wheels with a 1/2 in. hex bore. You'll need a 2 mm machine key (am-1121) to complete the assembly and transmit torque from the motor.
This adapter is no longer available in the 0.75 in. length.
Specifications
- Bore: 8 mm Round
- Keyway Width: 2 mm
- Length: 0.5 in., 1 in.
- Material: Steel
- Weight: 0.03 lbs
- Width: 0.497 - 0.499 in.
#10-32 x 0.625" SHCS - Min 25
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 10-32
- Length: 5/8 inch
- Head: Socket Head Cap Screw
- Yellow Nylon Thread Lock Patch
10-32 x 1.5 in. Socket Head Cap Screw
Specifications
- Drive: 5/32 in. Hex
- Finish: Zinc
- Head: Socket Cap
- Length: 1.5 in.
- Material: Steel
- Thread: 10-32
- Weight: 0.02 lbs
This item can only be purchased in multiples of 10
1/4-20 Nylock Nut
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 1/4-20
- Width across hex: 7/16"
This item can only be purchased in multiples of 25
1/4-20 x 1.5 in. Socket Head Cap Screw
Standard 1/4-20 Socket Head Cap Screw (SHCS) that's 1.5 in. long.
Specifications
- Drive: 3/16 in. Hex
- Head: Socket Cap
- Length: 1.5 in.
- Material : Steel
- Plating: Zinc
- Thread: 1/4-20
- Weight: 0.01 lbs
This item can only be purchased in multiples of 10
1/4-20 x 3 in. Socket Head Cap Screw
1/4-20 x 3" Long Socket Head Cap Screw
Specifications:
- Material: Steel
- Coating: Zinc plated
- Thread: 1/4-20
- Length: 3 inch
- Head: Socket Head Cap Screw
- Weight: 0.426 pounds
1 in. Tee Gusset
We are pleased to offer these new gussets that are suitable for 1" based building systems. These thoughtfully designed gussets are made from 1/8" thick 6061-T6 aluminum, which is a much stronger material than other 0.09" 5052 gussets. All of these framing gussets feature a 1" linear hole pattern, with holes suitable for either #10 screws or 3/16" rivets.
On all of the angle gussets, a generous radius was used on the inside corner for maximum strength. The various angle gussets, along with the quad and tee gusset are used together to create structures and sub-assemblies for your robot. Our bearing and Sport gussets are perfect building blocks to create a massive variety of mechanisms and assemblies to suit your needs.
Specifications
- Hole Pattern: Plates feature 0.20 in. Holes on a 1 in. Center to Center Spacing
- Material: 6061-T6 Aluminum
- Thickness: 0.125 in
2.5 inch CIM Motor
The CIM motor is a tried and true FIRST Robotics Competition workhorse motor. This brushed DC motor is 2.5 inches in diameter and kicks out 337 watts of power.
Pinion Options:
The CIM motor shaft is 0.313 in. (8 mm) in diameter and 1.25 inches long. It features a 2 mm wide machine key slot allowing installation of any number of custom or off the shelf pinions such as those included with all of our CIM based gearboxes. Other options include a pre-attached 16 tooth pinion making the CIM ready to mate to a CIM Sport planetary gearbox or a pre-attached 15 tooth pinion preparing the CIM for an EVO Gearbox. Use either of these two options if you are planning on using either the CIM Sport or an EVO gearbox and don't want to install the press fit pinion yourself. All of our other CIM based gearboxes use a slip fit pinion & machine key and are easy for the end user to install.
Compatible Components:
- Long CIM Motor Key - 2x2x14 mm Machine Key (am-0032)
- CIM Motor Key - 2x2x10 mm Machine Key, steel (am-1121)
- Retaining Ring for CIM Shaft - Retaining Clip, 8 mm id (am-0033)
Motor Etching
- Logo: AndyMark Logo
- Voltage and Name: 12VDC 2.5" CIM MOTOR
- CCL part number: PM25R-45F-1003
- Manufacturing date: MMDDYY
Specifications
- Bolt Pattern: 2 #10-32 Holes on a 2 in. diameter bolt circle
- Duty Cycle: Intermittent
- Free Current: 2.7 AMPs
- Free Speed: 5310 RPM
- Maximum Power: 337 Watts
- Output Shaft Diameter: 0.313 in. (8mm)
- Output Shaft Length: 1.245 in.
- Stall Current: 133 AMPs
- Stall Torque: 343.4 in-oz
- Voltage: 12 Volts DC
- Weight: 2.8 lbs
2x2x10 mm Machine Key, steel
Machine Key, steel. Used in 2.5" CIM Motor shafts.
Specifications:
- Width: 2mm (0.078 inch)
- Length: 10mm (0.394 inch)
- Weight: 0.0008 pounds
0.118 in. Thick 24 in. x 24 in. Polycarbonate Sheet
This is a single sheet of 1/8 inch thick polycarbonate (PC) plastic, cut to a 24x24 inch square. This single sheet of PC will be shipped with the protective covering on both sides of the plastic sheet.
Polycarbonate was invented in 1963 by Dan Fox at General Electric. GE's trade name for this plastic is LEXAN, but it also is sold under other trade names (Makrolon, Hyzod, Cyrolon).
This material is NOT plexiglas or acrylic, as we don't suggest that you use that material on a mobile robot, since acrylic will easily shatter.
Specifications:
- Weight: 2.9 pounds
- Width: 24 inches
- Length: 24 inches
- Material thickness: 0.118 inch
- Material: Clear Polycarbonate
Retainer Clip, 8mm id
This retainer clip is used to hold objects (such as gears) in place on shafts.
Example: This product can be used to hold a gear onto a CIM motor shaft.
Specification:
- Material: Steel
- Inner Diameter: 8mm
- Outer Diameter: 15mm
- Weight: Less than 0.001 lbs
Box Tube Extrusion, 1 X 1 in., .063 Wall Thickness, 6 ft. Length
These aluminum box extrusions are robust and lightweight solutions for custom robot frames, superstructures and mechanism construction. Made to all of your favorite English sizes, the classic 2x1 thin wall tubing is now joined by its thicker-walled counterpart. We have also introduced two thicknesses of 1x1 sizes that teams know and love to build their medium-sized mechanisms.
For smaller mechanisms, we recommend using our 5/8 square box tube that is also compatible with our S3 line of brackets and gussets.
Available Sizes:
- 2 x 1 x 1/16 in. (0.063 in.) 6061-T6 alloy
- 2 x 1 x 1/8 in. (0.125 in.) 6061-T6 alloy
- 1 x 1 x 1/16 in. (0.063 in.)6061-T6 alloy
- 1 x 1 x 1/8 in. (0.125 in.)6061-T6 alloy
- 5/8 x 5/8 x 1/16 in. (0.063 in.) 6061-T6 alloy
- All lengths are (+/- 1in)
Be sure to all check out our Gussets as they work wonderfully with all of these wonderful extrusions.
Specifications
- Material: Aluminum
Documents
Layout Print(s)
am-3214 2x1x0625 6061-T6 wall tubing.PDF
am-4203 1x1x063 wall tubing.PDF
am-4204 1x1x0.125 wall tubing.PDF
am-4205 2x1x0.125 wall tubing.PDF
CAD File(s)
am-3214 2x1x0625 wall tubing.STEP
am-4203 1x1x0625 wall tubing.STEP
QTY 8 - Aluminum T Gussets - 5mm Hole Size
This 8 pack of 2.5mm thick T gussets can be used to assemble structures used in competitive robotics.
- 3.50 in. x 3.25 in. with 1 inch wide ends
- 5mm (.197") holes spaced 1/2 an inch apart, perfect for number 10 bolts or 3/16 rivets.
- 2.5mm (0.098 in.) thick, made from 6061-T6 aluminum
- Sold in 8 packs
10-32 x 1.5 in. Button Head Cap Screw
This button head cap screw features a 10-32 thread and is 1.5 in. long.
Specifications
- Drive: 1/8 in. Hex
- Finish: Zinc
- Head: Button Head Cap Screw
- Length: 1.5 in.
- Material: Steel
- Thread: 10-32
- Weight: 0.011 lbs
This item can only be purchased in multiples of 10
Top Corner Bracket
These plates are included in the 2024 KitBot. Made from 0.125 in. Aluminum, these Plates are used for various structures throughout the KitBot.
Quantity of each plate included in the 2024 KitBot:
- 2 - Top Corner Bracket (am-5294)
- 2 - Tube Mounting Plate (am-5296)
- 1 - Motor Mount Plate (am-5295)
Specifications
- Material: Aluminum
- Thickness: 0.125 in.
Motor Mount Plates
These plates are included in the 2024 KitBot. Made from 0.125 in. Aluminum, these Plates are used for various structures throughout the KitBot.
Quantity of each plate included in the 2024 KitBot:
- 2 - Top Corner Bracket (am-5294)
- 2 - Tube Mounting Plate (am-5296)
- 1 - Motor Mount Plate (am-5295)
Specifications
- Material: Aluminum
- Thickness: 0.125 in.
Documents
CAD File(s)
am-5294 KitBot 2024 Top Corner Bracket.STEP
