Inline Pressure Gauge with 1/4 in. Press-in Tube Fittings

Secure Powerpole connections with these easy to use Powerpole Clips. Don't worry about your power pole connections coming loose during those important times and when the time comes to swap components, the clip comes out easily. Works for PP15, PP30 and PP45.

This item can only be purchased in multiples of 10

These connecting chain attachment links, also known as K-links, are perfect for securing components that need movement, to a chain. These versions were specifically designed by AndyMark to interface with common FRC and FTC products. The #35 chain version is designed for #10 hardware on a 1 on. hole spacing. The #25 chain version is designed for #6 hardware with 16 mm (5/8 in.) hole spacing. Both versions make it much easier to interface chain to elevator systems than ever before. They can also be used in conveyor systems to move items around inside your robot.

Specifications

• Chain Size: #25, #35
• Hole Size: #25: 0.150 in., #35: 0.201 in.
• Hole Spacing: #25: 16 mm, #35: 1.00 in.
• Load Capacity : #25: 150lb, #35: 300lb
• Material: Steel
• Pitch: #25: 0.250 in., #35: 0.375 in.
• Weight: 0.01 lbs

Documents

Layout Print(s)

am-4181_25 25 Chain Attachment Link.PDF

am-4181_35 35 Chain Attachment Link.PDF

CAD File(s)

am-4181_35 35 Chain Attachment Link.STEP

am-4181_25 25 Chain Attachment Link.STEP

These connecting chain attachment links, also known as K-links, are perfect for securing components that need movement, to a chain. These versions were specifically designed by AndyMark to interface with common FRC and FTC products. The #35 chain version is designed for #10 hardware on a 1 on. hole spacing. The #25 chain version is designed for #6 hardware with 16 mm (5/8 in.) hole spacing. Both versions make it much easier to interface chain to elevator systems than ever before. They can also be used in conveyor systems to move items around inside your robot.

Specifications

• Chain Size: #25, #35
• Hole Size: #25: 0.150 in., #35: 0.201 in.
• Hole Spacing: #25: 16 mm, #35: 1.00 in.
• Load Capacity : #25: 150lb, #35: 300lb
• Material: Steel
• Pitch: #25: 0.250 in., #35: 0.375 in.
• Weight: 0.01 lbs

Documents

Layout Print(s)

am-4181_25 25 Chain Attachment Link.PDF

am-4181_35 35 Chain Attachment Link.PDF

CAD File(s)

am-4181_35 35 Chain Attachment Link.STEP

am-4181_25 25 Chain Attachment Link.STEP

This is a heavy-duty compression lug from BURNDY for 06 AWG wire. This compression log can be easily crimped with the Cable Lug Crimping Tool.

Specifications

• Gauge: 06 AWG
• Hole Size For Stud: 0.25 in.
• Material: Copper
• Overall Length: 2.03 in.
• Tongue Width: 0.48 in.
• Weight: 0.01 lbs
• Wire Strip Length: 1.18 in.

This is a push-to-connect "Y" fitting.

Specifications:

• Weight: 0.02 lbs
• Width: 1.515 in
• Height: 0.56 in
• Depth: 1.31 in
• Material: plastic body material
• Ports: 1/4" push-to-connect fitting
• Pressure range: 0-150 psi

This is a miniature pressure gauge with 1/8 in. NPT threads perfect for lightweight pneumatic systems where you need to mount a pressure gauge to a hard fitting. This pressure gauge is significantly reduced in volume and weight compared to the classic gauges used in FRC. This lets you take advantage of every last cubic inch and ounce on your robot.

Specifications

• Height: 0.83 in
• Operating Pressure: 0-150 psi
• Port(s): 1/8 in. NPT
• Pressure Range : 0-116 psi
• Width: 0.59 in

This is a plastic air tank accumulator holding 574 ml, manufactured by Clippard.

This black plastic tank has been improved over the last white plastic design from Clippard. Each end now has molded in plastic push-in fittings. These eliminate the need to have metal fittings to be screwed in to the tank, and omits the uncertainty of over-tightening a fitting into the tank.

Specifications:

• Manufacturer: Clippard
• Weight: 0.64 lbs
• Capacity: 574 ml (35 cu. inch)
• Ports: Two 1/4" od tube push-in fittings
• Maximum pressure: 125 psig
• Temperature rating: 35 to 100 F
• Length: 12.25"
• Diameter: 2.5" (@ main tank), 2.75" max

A mounting bracket is available to order (am-2008), but is not included when ordering just this item.

Note: If you have received a faulty air tank (damaged push to connect fittings) please contact Scott Lamb of Clippard Technical Sales at (513)-521-4445 (ext 1213).

This 20 Amp fuse is used in FIRST Tech Challenge batteries and the FIRST Robotics Competition Power Distribution Panel (am-2856).

Specifications:

• Color: Yellow
• Amps: 20
• Max Voltage: 32
• Style: MINI®
• Specification: SAE J2077
• Type: Blade Fuse

This is an all in one in-line pressure regulator and low pressure side gauge perfect for lightweight pneumatic systems where you need to mount a regulator somewhere downstream in the system.

The MINI® Fuse is the standard for vehicle circuit protection. Its miniature design meets the need for more circuits to be protected while utilizing less space, and its ability to cope with high temperatures in adverse environments makes the MINI® Fuse of recommended choice for protection.

This mini fuse can be used in our Power Pole Distribution Board (am-3699), as well as a replacement in the Power Distribution Panel (am-2856)
