Here is a versatile extruded aluminum, hex profile. The outside of this part is a 1/2" hex with small concave dimples which act as weight savings. There is an inside hole tapped to 1/4-20 thread profile.

The outside hex size fits a 1/2" wrench or socket.

Specifications:

• Material: 6063 Aluminum
• Inside thread: 1/4-20
• Outside width: 0.495 inch hex, across flats
• Length: 0.99 (+/- 0.02) inch
• Weight: 0.014 pound

This motor plate accepts one or two AndyMark 775 RedLine Motors (am-3775) for use in a DeCIMate Gearbox (am-3745). This plate forms the structure of the DeCIMate gearbox along with the Output Plate for DeCIMate (am-3692).

Specifications:

• Material: 6061-T6 Aluminum
• Thickness: 0.25 in.
• Length: 2.9 in.
• Height: 1.5 in.
• Weight: 0.06
• Finish: Anodized Red

This output plate forms the structure of the DeCIMate Gearbox (am-3745) along with the DeCIMate Motor Plate (am-3693). This plate mimics the mounting features of a CIM motor meaning anywhere you could mount a CIM, there too the DeCIMate can go.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness: 0.25 in.
• Length: 2.5 in.
• Height: 2.5 in.
• Weight: 0.089
• Finish: Anodized Red

Three (3) straight 1/8 NPT fittings (or right angle 1/8 NPT fittings) are NOT INCLUDED with this part, but are needed to connect tubing to this valve.

Specifications:

• Type: In-line, individual
• Size: 170mm x 67mm x 22mm
• Valve function: 5 Port-2 Position
• Port size: 1/8" NPT
• pilot air supply: Internal
• Cable length:
• Voltage: 12Vdc
• Weight: 0.72 lbs
• Pressure Range: 22 - 116 psi
• Max. pressure: 215 psi
• Max Response Time: 50ms
• Flow rating: 0.78 Cv

This updated version of the Encoder Mount Pad now adds compatibility with the popular CUI Inc. AMT-103 Encoder, previously available in FIRST Choice. This Encoder Mount Pad retains compatibility with the US Digital E4P and E4T series of encoders, as well as the CTRE SRX Magnetic Encoder.

Encoder Mount Pad V2 Compatible Products:

• AM Shifter (Gen1 and Gen 2)
• Super Shifter
• Sonic Shifter
• Super Sonic Shifter
• SpinBox
• Toughbox
• Nano Tube
• RocketBox PTO
• AfterBurner Winch Kit
• RAW Box
• LJ Bevel Box
• 3CIM4U
• CIM-Sim
• EVO Shifter
• EVO Slim

Note: This product is not required to mount encoders to the Toughbox Mini, Toughbox Micro or CIMple Box gearboxes.

Specifications:

• Material: Black Polycarbonate
• Length: 2.00 in.
• Width: 0.75 in.
• Thickness: 0.240 in.
• Weight: 0.006 Pounds

Specifications:

• Diameter: 3.575" (not including tread)
• Width: 1.00"
• Width at Hub: 1.64"
• Bore: 1.124 inch bore, 0.25" deep on either side
• Bolt Pattern: 6 Holes around a 1.875" diameter circle
• Body Material: Black Polycarbonate
• Load Capacity: 200 pounds (estimated)
• Weight: 0.42 pounds
• Tread Capture: 0.9 inch wide (clamps tread)
• Tread Width: 1 inch

Included Hardware:

• Two - 4" Plaction Wheel Halves
• Six - Individual #10-32x1.5" SHCS (am-1014)
• Six - Individual #10-32 Nylock Nuts

Usage:

• There are two ways to drive this wheel. One way is with a Axle and Hub, and the other is with a Sprocket. To install a sprocket or hub onto a Plaction wheel, use 10-32 x 1.75" socket head screw (qty. 3 or 6), and 10-32 nylock nuts. To use one sprocket on each side of a Plaction wheel (2 sprockets total) use 10-32 x 2.5" screws (3 or 6) and 10-32 nylock nuts.

With Axle and Hub:

• If you wish to drive this wheel with an Axle and Hub, you can pick your hub by fitting any of the AndyMark hubs (except the Small DD Globe Hub) to this wheel. Hubs are NOT included in the price of the wheel. If this is your choice, then no bearing is needed.

With Sprocket:

• If you wish to drive this wheel with a sprocket, then the sprocket needs to be attached to the side of the wheel, and two ball bearings need to be pressed into the wheel (one on each side). The smallest sprocket that will work with these wheels is a S35-24 tooth and a S25-36 tooth sprocket.

With Bearing:

• If your design needs this wheel to spin on a stationary axle (and possibly be driven by a sprocket), you will need 2 bearings with a 1.125" od pressed into this wheel. Use am-0029 for a 1/2" bore and am-0209 for a 3/8" bore. One bearing is pressed into each side of the wheel. Bearings are NOT included in the price of this wheel.

With Tread:

• This wheel is designed to capture 1" wide conveyor belt tread (Roughtop or Wedgetop) between 2 wheel halves. The 6 perimeter screws can be loosened by 1/8 inch to install the desired tread. We recommend using Alligator Clips to hold the tread together on the wheel. Treads are NOT included in the price of the wheel.

For a Wider Wheel:

• This wheel is designed so that a 3" PVC schedule 40 pipe can be inserted between the two wheel halves, and a wider wheel can be created.

Molded polycarbonate, 4 inch diameter high traction wheel with Wedgetop tread

Specifications:

• Diameter, Plaction: 4"
• Diameter, Tread Peaks: 4.37"
• Width: 1.00 inch
• Width at Hub: 1.64 inches
• Bore: 1.124 inch bore, 0.25 inches deep on either side
• Bolt Pattern: 6 Holes around a 1.875" diameter circle
• Body Material: Black Polycarbonate
• Load Capacity: 200 pounds (estimated)
• Weight: 0.49 pounds
• Tread Capture: 0.9 inch wide (clamps tread)
• Tread Width: 1 inch
• Tread Type: Wedgetop Conveyor Belting, Natural Rubber

Included Hardware:

• Two - 4" Plaction Wheel Halves
• Six - Individual #10-32 x 1.5" SHCS (am-1014)
• Six - Individual #10-32 Nylock Nuts
• One - 4" Wheel Wedgetop Tread
• Two - Individual Alligator Clips
• One- Individual Alligator Clip Pins

Usage:

• There are two ways to drive this wheel. One way is with a Axle and Hub, and the other is with a Sprocket. To install a sprocket or hub onto a Plaction wheel, use 10-32 x 1.75" socket head screw (qty. 3 or 6), and 10-32 nylock nuts. To use one sprocket on each side of a Plaction wheel (2 sprockets total) use 10-32 x 2.5" screws (3 or 6) and 10-32 nylock nuts.

With Axle and Hub:

• If you wish to drive this wheel with an Axle and Hub, you can pick your hub by fitting any of the AndyMark hubs (except the Small DD Globe Hub) to this wheel. Hubs are NOT included in the price of the wheel. If this is your choice, then no bearing is needed.

With Sprocket:

• If you wish to drive this wheel with a sprocket, then the sprocket needs to be attached to the side of the wheel, and two ball bearings need to be pressed into the wheel (one on each side). The smallest sprocket that will work with these wheels is a S35-24 tooth and a S25-36 tooth sprocket.

With Bearing:

• If your design needs this wheel to spin on a stationary axle (and possibly be driven by a sprocket), you will need 2 bearings with a 1.125" od pressed into this wheel. Use am-0029 for a 1/2" bore and am-0209 for a 3/8" bore. One bearing is pressed into each side of the wheel. Bearings are NOT included in the price of this wheel.

With Tread:

• This wheel is designed to capture 1" wide conveyor belt tread (Roughtop or Wedgetop) between 2 wheel halves. The 6 perimeter screws can be loosened by 1/8 inch to install the desired tread. We recommend using Alligator Clips to hold the tread together on the wheel. One 4" wheel Wedgetop Tread is included in the price of the wheel.

For a Wider Wheel:

• This wheel is designed so that a 3" PVC schedule 40 pipe can be inserted between the two wheel halves, and a wider wheel can be created (additional tread may be needed).

The inside black portion of this wheel is made from molded polycarbonate plastic. The outer tread is TPU (Thermoplastic PolyUrethane). This robust but lightweight wheel provides good traction on carpet and soft tiles. Stealth wheels are the perfect drive wheel for smaller (<50 lb.) robots, or for intakes and other auxiliary robot mechanisms. These wheels are available in a variety of bores and durometers. 4 in. Stealth Wheels feature a 6 bolt pattern on a 1.875 in. bolt circle for mounting sprockets, hubs, and gears. Nub Bore Stealth Wheels feature a 4 bolt pattern on a 16 mm bolt circle found in most FIRST Tech Challenge building systems. The lower the durometer the softer the wheel is, this makes it wear away faster, but also makes it more grippy.

Product Usage:
Many thread locking materials are not compatible with polycarbonate and can eat away at the plastic. Be sure to check which adhesives are okay to use with this product.

Specifications

• Bore: 1/2 in. Hex, 3/8 in. Hex, Nub Bore, 5 mm Hex
• Diameter: 2 in., 4 in.
• Durometer: 35A (Green), ⠀40A (Orange), ⠀50A (Blue), ⠀60A (Black), ⠀80A (Gray)
• Hole Pattern: Qty 4 3.5 mm Holes on a 16 mm Circle for 8 mm bore wheels
• Material: TPU, Polycarbonate
• Weight: 0.23lb, 0.1lb
• Width: 1 in.
