Face Bearing Block

The Studica Slide Rail is made of light weight aluminum, is 24mm wide, and is perfect for building a multi-stage slide system. Closed length is 384m, with a 240mm stroke, creating a 530mm extended length.

IN STOCK

• Width: 24mm
• Height: 7.2mm
• Length: 384mm
• Stroke: 240mm
• Extendended length: 530mm
• Material: 6061 Aluminum
• Step file

Used with Studica Omni and Mecanum wheels for a strong axel hold.

Specifications:

• Material: 6061-T6 Aluminum
• Color: Blue
• Step File

The Studica Low Profile U Channel is 3mm thick and has a 48mm x 14mm profile. As with the other Studica Robotics building components, it has the common hole pattern which makes it easy to connect to other structure with very little or no additional machining required. You can easily connect to other channel, extrusions, bushings, bearing, mounting brackets and more so you can quickly assemble and disassemble robots and automated systems.

Specifications:

• Material: 6061-T6 Aluminum
• Thickness - 3mm
• Height - 14mm
• Width - 48mm
• Length - 48mm
• Hole pattern - 1
• Step File

The M3 x 10mm Low Profile Screw with Kep Nut is a 304 Stainless Steel m3 Din 7991 Countersunk Hex Socket Flat Head Screw with a matching Kep Nut. This package is made for the Slide Rail, 288mm Length, 180mm Stroke and the Slide Rail, 384mm Length, 240mm Stroke

Includes,

• 6 - M3 x 10mm Low Profile Screw
• 6 - Kep nut

The Studica Threaded Pattern Plate can be used to join two different structure components together.

Specifications:

• OD: 28mm
• ID: 14mm
• Thickness: 3mm
• Holes: 8 x M3 x 3mm Tap Through
• Material: 6061-T6 Aluminum, Blue Anodized
• Step File

The Studica Threaded Joiner Plate can be used to join two different structure components together, such as U Channel and brackets.

Specifications:

• Length: 24mm
• Width: 22mm
• Height: 3mm
• Holes: 10 x M3 x 3mm Tap Through
• Material: 6061-T6 Aluminum, Blue Anodized
• Step File

The Studica Light Weight Shaft Hub is used with the 6mm D shafts. It has a 5mm set screw for tight clamping and seven M3 tapped mounting holes.

Specifcation:

• Material: 6061-T6 Aluminum
• 6mm D Shaft ID
• M3 tapped hole pattern for connecting to structure
• Step File

The Studica Linear Servo RC Actuator 50-200 is a new Servo motor which has a stroke of 50mm. It works the same way as the any standard rotary servo but in a linear movement. It uses the same 2.54mm Dupont 3-Pin Female wire connector and can be controlled with an RC receiver or any device that controls a servo. Includes mounting brackets.

M3 x 10mm Socket Head Cap Screw (pack of 100), Zinc Plated.

• Step File

M3 x 10mm Button Head Cap Screw (pack of 50), Zinc Plated.

• Step File
